[SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:TRIGger:DELay
<shift_stimulus>
Defines an offset time (shift stimulus) for the wave quantity assigned to the measurement receiver
<rec_no> and the external generator <gen_no>.
<Ch>
Channel number
<rec_no>
Number of the measurement receiver (= port number of the analyzer). Values
range from 1 to the total number of test ports.
<gen_no>
Number of a previously configured external generator
<shift_stimulus>
Offset time
Range [def. unit]
–0.003 s to +0.003 s [s]. The increment (UP/DOWN) is 50 ns.
*RST value
0 s
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:MODE
[SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:SRCPort<port_no>:EVALuation:MODE
NORMal | MEAN
Specifies whether the wave quantity assigned to the measurement receiver <rec_no> and the analyzer
source port <port_no> is displayed as measured or whether it is averaged.
<Ch>
Channel number
<rec_no>
Number of the measurement receiver (= port number of the analyzer). Values
range from 1 to the total number of test ports.
<port_no>
Number of the analyzer source port. 1 to the total number of test ports.
Parameters
NORMal – wave quantity is as measured (pulse shape)
MEAN – wave quantity is replaced by its mean value (magnitude and phase)
averaged over a configurable time interval; see example below
*RST value
NORMal
SCPI, Command
Types
Device-specific, command or query
Example:
PULS:REC:B2:SRCP2:EVAL:STAR 200 ns; STOP 500 ns
Specify the averaging section for the b
2
receiver and the analyzer source port no.
2: Define a start value of 200 ns and a stop value of 500 ns.
PULS:REC:B2:SRCP2:LIN ON
Display the section limit lines in the diagram.
PULS:REC:B2:SRCP2:EVAL:MODE MEAN
Enable averaging of the b
2
wave.
PULS:REC:B2:SRCP2:TRIG:DEL 100 ns
Shift the stimulus axis of the b
2
wave by 100 ns.
