R&S ZVB - Page 986

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 971
[SENSe<Ch>:]TEUNit:UMEas<Path>[:STATe] <Boolean>
Enables/disables the user measurement path extension for RF signal path <Path>.
<Ch>
Channel number
<Path>
Signal path no. 1 or 2. If unspecified, this parameter is set to 1.
<Boolean>
ON – User meas path extension enabled
OFF – User meas path extension disabled (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:UME1 ON
Enable the user measurement path extension for path 1
[SENSe<Ch>:]TEUNit:USOurce<Path>[:STATe] <Boolean>
Enables/disables the user source path extension for RF signal path <Path>.
<Ch>
Channel number
<Path>
Signal path no. 1 or 2. If unspecified, this parameter is set to 1.
<Boolean>
ON – User source path extension enabled
OFF – User source path extension disabled (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:USO1 ON
Enable the user source path extension for path 1
[SENSe<Chn>:]UDSParams<Pt>...
This subsystem defines user-defined (virtual) ports. All commands are supported for compatibility with
R&S ZVR functionalities.
User-defined S-parameters are intended for standard S-parameter measurements. They are not
compatible with special measurement modes such as True Differential Mode or Defined Coherence Mode.
[SENSe<Ch>:]UDSParams<Pt>:ACTive <Boolean>
Enables or disables the user-defines S-parameters for channel <Ch> and port no. <Pt>.
<Ch>
Channel number
<Pt>
Physical analyzer port number
<Boolean>
ON | OFF – Enable or disable user-defined S-parameters
