If unspecified, this parameter is set to 1.
<Boolean>
ON – Input is inverted
OFF – Input is not inverted
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:PMOD1:INV ON
Invert pulsed source signal modulator at path 1
[SENSe<Ch>:]TEUNit:REAR<No>:SOURce G1INt | G2INt | G1Ext | G2Ext | OFF
Defines the source signal for pulse generator output <No> of the R&S ZVAX-TRM.
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<No>
Ext. OUT no. 1 or 2.
If unspecified, this parameter is set to 1.
Parameters
G1INt – internal pulse generator (via CASCADE IN)
G2INt – internal sync generator (via CASCADE IN)
G1EXt – external generator 1 (via EXT PULSE GENERATOR 1)
G2EXt – external generator 2 (via EXT PULSE GENERATOR 2)
OFF
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
TEUN:REAR1:SOUR G1IN
Propagate internal pulse generator signal 1 to external pulse generator
output 1
[SENSe<Ch>:]TEUNit:REAR<No>:INVert <Boolean>
Defines whether the signal at the pulse generator output no. <No> shall be inverted.
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<No>
Ext. OUT no. 1 or 2.
If unspecified, this parameter is set to 1.
<Boolean>
ON – Input is inverted
OFF – Input is not inverted
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:PORT1:INV ON
Invert signal at external pulse generator output 1
