R&S ZVB - Page 984

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 969
Example:
TEUN:LNAM1 ON
Switch low noise amplifier into receive path 1
[SENSe<Ch>:]TEUNit:PMODulator<Path>[:STATe] <Boolean>
Loops a pulse modulator into the RF signal path no. <Path>.
<Ch>
Channel number
<Path>
Signal path no. 1, 2, or 3. If unspecified, this parameter is set to 1.
<Boolean>
ON – Pulse modulator used
OFF – No pulse modulator (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:PMOD1 ON
Loop pulse modulator into path 1
[SENSe<Ch>:]TEUNit:PMODulator<Path>:SOURce G1INt | G2INt | G1Ext | G2Ext |
OFF
Selects the source (i.e. the pulse generator) for the pulse modulator at RF path <Path>.
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<Path>
Signal path no. 1, 2 or 3.
If unspecified, this parameter is set to 1.
Parameters
G1INt – internal pulse generator (via CASCADE IN)
G2INt – internal sync generator (via CASCADE IN)
G1EXt – external generator 1 (via EXT PULSE GENERATOR 1)
G2EXt – external generator 2 (via EXT PULSE GENERATOR 2)
OFF
*RST value
G1INt
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:PMOD3:SOUR G1IN
Select the internal pulse generator as source for path 3
[SENSe<Ch>:]TEUNit:PMODulator<Path>:INVert <Boolean>
Invert the source of the pulse modulator on RF path <Path>.
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<Path>
Signal path no. 1, 2 or 3.
