R&S ZVB - Page 983

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 968
[SENSe<Ch>:]TEUNit:COMBiner<Path>[:STATe] <Boolean>
Switches the internal combiner in-between RF signal paths 1 and 3 or 2 and 4 (source path).
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<Path>
Signal path, must be set to 1 or 2 (defaults to 1 if omitted).
<Boolean>
ON – Internal combiner used. The combined source signals of paths <path>
and <path>+2 are available at the NWA port <path>.
OFF – No combiner used for paths <path> and <path>+2.
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
TEUN:COMB ON
Activate the internal combiner for RF paths 1 and 3.
[SENSe<Ch>:]TEUNit:PAMPlifier<Path>[:STATe] <Boolean>
Loops an internal power amplifier into one of the RF signal paths (source paths).
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<Path>
Signal path no. 1, 2, 3 or 4.
If unspecified, this parameter is set to 1.
<Boolean>
ON – Power amplifier used
OFF – Power amplifier not used (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
TEUN:PAMP1 ON
Switch Power amplifier into path 1
[SENSe<Ch>:]TEUNit:LNAMplifier<Path>[:STATe] <Boolean>
Loops an internal low noise amplifier into receive path 1 or 2.
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<Path>
Signal path no. 1 or 2.
If unspecified, this parameter is set to 1.
<Boolean>
ON – Low noise amplifier used
OFF – Low noise amplifier not used (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
