is swept in linear, equidistant steps over a continuous range
(SOURce<Ch>:POWer<Pt>:STARt, SOURce<Ch>:POWer<Pt>:STOP). In a
Cartesian diagram, the x-axis is a dB-linear power axis.
CW
Time sweep. The measurement is performed at constant frequency
(SOURce<Ch>:FREQuency<Pt>:CW|FIXed) and source power
(SOURce<Ch>:POWer<Pt>[:LEVel][:IMMediate][:AMPlitude]) and
repeated over a specified period of time at constant time intervals.
POINt
CW Mode sweep, time sweep triggered according to the current trigger settings.
PULSe
Pulse profile mode, configured via SENSe:PULSe...
IAMPlitude
Amplitude imbalance sweep, configured via SOURce:TDIF...
IPHase
Phase imbalance sweep, configured via SOURce:TDIF...
*RST value
LINear
SCPI,
Command
Types
Device-specific, command or query
Example:
FUNC "XFR:POW:S12"
Activate a frequency sweep and select the S-parameter S12 as measured parameter
for channel and trace no. 1.
SWE:TYPE LOG
Change to sweep type Log Frequency.
[SENSe<Ch>:]TEUNit...
This subsystem configures the different signal paths in the Extension Unit R&S ZVAX-TRM and selects
the connectors for the pulse generators.
[SENSe<Ch>:]TEUNit:AMONitor<Path> PMODulator | COMBiner | OUTPut
Selects the input for the a-wave (REF) receiver at paths no. 1-4.
<Ch>
Channel number. If unspecified, this parameter is set to 1.
<Path>
Signal path, must be set to 1...4 (defaults to 1 if omitted).
Parameters
Position of the a-wave access in the RF path:
 PMODulator: before the pulse modulator (only available for paths
1,2 and 3)
 COMBiner: before the combiner
 OUTPut: at the output.
*RST value
OUTPut
SCPI, Command
Types
Device-specific, command or query
Example:
TEUN:AMON3 COMB
On path 3, measure the a-wave before the combiner
