INTERRUPT CONTROLLER (ICU)
32180 Group User’s Manual (Rev.1.0)
5.2 ICU Related Registers
5.2 ICU Related Registers
The diagram below shows a register map associated with the Interrupt Controller (ICU).
ICU Related Register Map
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0000 Interrupt Vector Register 5-5
(IVECT)
H'0080 0002 (Use inhibited area)
H'0080 0004 Interrupt Request Mask Register (Use inhibited area) 5-6
(IMASK)
H'0080 0006 SBI Control Register (Use inhibited area) 5-7
(SBICR)
(Use inhibited area)
H'0080 0060 CAN0 Transmit/Receive & Error Interrupt Control Register TIN30–33 Input Interrupt Control Register 5-8
(ICAN0CR) (ITIN3033CR)
H'0080 0062 TID2 Output Interrupt Control Register A-D1 Conversion Interrupt Control Register 5-8
(ITID2CR) (IAD1CCR)
H'0080 0064 SIO4,5 Transmit/Receive Interrupt Control Register TOU1,2 Output Interrupt Control Register 5-8
(ISIO45CR) (ITOU12CR)
H'0080 0066 TID1 Output Interrupt Control Register RTD Interrupt Control Register 5-8
(ITID1CR) (IRTDCR)
H'0080 0068 SIO2,3 Transmit/Receive Interrupt Control Register DMA5–9 Interrupt Control Register 5-8
(ISIO23CR) (IDMA59CR)
H'0080 006A TOU0 Output Interrupt Control Register TID0 Output Interrupt Control Register 5-8
(ITOU0CR) (ITID0CR)
H'0080 006C A-D0 Conversion Interrupt Control Register SIO0 Transmit Interrupt Control Register 5-8
(IAD0CCR) (ISIO0TXCR)
H'0080 006E SIO0 Receive Interrupt Control Register SIO1 Transmit Interrupt Control Register 5-8
(ISIO0RXCR) (ISIO1TXCR)
H'0080 0070 SIO1 Receive Interrupt Control Register DMA0–4 Interrupt Control Register 5-8
(ISIO1RXCR) (IDMA04CR)
H'0080 0072 TIO0–3 Output Interrupt Control Register TOP6,7 Output Interrupt Control Register 5-8
(ITIO03CR) (ITOP67CR)
H'0080 0074 TOP0–5 Output Interrupt Control Register TOP8,9 Output Interrupt Control Register 5-8
(ITOP05CR) (ITOP89CR)
H'0080 0076 TIO4–7 Output Interrupt Control Register TOP10 Output Interrupt Control Register 5-8
(ITIO47CR) (ITOP10CR)
H'0080 0078 TOP8,9 Output Interrupt Control Register TMS0,1 Output Interrupt Control Register 5-8
(ITOP89CR) (ITMS01CR)
H'0080 007A TIN7–11 Input Interrupt Control Register TIN0–2 Input Interrupt Control Register 5-8
(ITIN711CR) (ITIN02CR)
H'0080 007C TIN12–19 Input Interrupt Control Register TIN20–29 Input Interrupt Control Register 5-8
(ITIN1219CR) (ITIN2029CR)
H'0080 007E TIN3–6 Input Interrupt Control Register CAN1 Transmit/Receive & Error Interrupt Control Register 5-8
(ITIN36CR) (ICAN1CR)
|
