INPUT/OUTPUT PORTS AND PIN FUNCTIONS
32180 Group User’s Manual (Rev.1.0)
P11 Operation Mode Register (P11MOD) <Address: H’0080 074B>
9 1011121314b15b8
P113MD
P112MDP111MDP110MD
P114MD P115MD P116MD P117MD
00000000
<After reset: H’00>
b Bit Name Function R W
8 P110MD 0: P110 R W
Port P110 operation mode bit 1: TO0
9 P111MD 0: P111 R W
Port P111 operation mode bit 1: TO1
10 P112MD 0: P112 R W
Port P112 operation mode bit 1: TO2
11 P113MD 0: P113 R W
Port P113 operation mode bit 1: TO3
12 P114MD 0: P114 R W
Port P114 operation mode bit 1: TO4
13 P115MD 0: P115 R W
Port P115 operation mode bit 1: TO5
14 P116MD 0: P116 R W
Port P116 operation mode bit 1: TO6
15 P117MD 0: P117 R W
Port P117 operation mode bit 1: TO7
P12 Operation Mode Register (P12MOD) <Address: H’0080 074C>
123456b7b0
P124MD P125MD P126MD P127MD
0000
0
0
0
0
<After reset: H’00>
b Bit Name Function R W
0–3 No function assigned. Fix to "0". 00
4 P124MD 0: P124 R W
Port P124 operation mode bit 1: TCLK0
5 P125MD 0: P125 R W
Port P125 operation mode bit 1: TCLK1
6 P126MD 0: P126 R W
Port P126 operation mode bit 1: TCLK2
7 P127MD 0: P127 R W
Port P127 operation mode bit 1: TCLK3
Note: • Ports P120–P123 are nonexistent.
