Renesas M32R/ECU Series User Manual

8
8-15
INPUT/OUTPUT PORTS AND PIN FUNCTIONS
32180 Group User’s Manual (Rev.1.0)
P13 Operation Mode Register (P13MOD) <Address: H’0080 074D>
9 1011121314b15b8
P133MD
P132MDP131MDP130MD
P134MD P135MD P136MD P137MD
00000000
<After reset: H’00>
b Bit Name Function R W
8 P130MD 0: P130 R W
Port P130 operation mode bit 1: TIN16/PWMOFF0 (Note 1)
9 P131MD 0: P131 R W
Port P131 operation mode bit 1: TIN17/PWMOFF1 (Note 1)
10 P132MD 0: P132 R W
Port P132 operation mode bit 1: TIN18
11 P133MD 0: P133 R W
Port P133 operation mode bit 1: TIN19
12 P134MD 0: P134 R W
Port P134 operation mode bit 1: TIN20
13 P135MD 0: P135 R W
Port P135 operation mode bit 1: TIN21
14 P136MD 0: P136 R W
Port P136 operation mode bit 1: TIN22
15 P137MD 0: P137 R W
Port P137 operation mode bit 1: TIN23
Note 1: TIN and PWMOFF inputs both are enabled.
P14 Operation Mode Register (P14MOD) <Address: H’0080 074E>
123456b7b0
P144MD P145MD P146MD P147MDP140MD P141MD P142MD P143MD
00000000
<After reset: H’00>
b Bit Name Function R W
0 P140MD 0: P140 R W
Port P140 operation mode bit 1: TIN8
1 P141MD 0: P141 R W
Port P141 operation mode bit 1: TIN9
2 P142MD 0: P142 R W
Port P142 operation mode bit 1: TIN10
3 P143MD 0: P143 R W
Port P143 operation mode bit 1: TIN11
4 P144MD 0: P144 R W
Port P144 operation mode bit 1: TIN12
5 P145MD 0: P145 R W
Port P145 operation mode bit 1: TIN13
6 P146MD 0: P146 R W
Port P146 operation mode bit 1: TIN14
7 P147MD 0: P147 R W
Port P147 operation mode bit 1: TIN15
8.3 Input/Output Port Related Registers
