INPUT/OUTPUT PORTS AND PIN FUNCTIONS
32180 Group User’s Manual (Rev.1.0)
P15 Operation Mode Register (P15MOD) <Address: H’0080 074F>
9 1011121314b15b8
P153MD
P152MDP151MDP150MD
P154MD P155MD P156MD P157MD
00000000
<After reset: H’00>
b Bit Name Function R W
8 P150MD 0: P150 R W
Port P150 operation mode bit 1: TIN0
9 P151MD 0: P151 R W
Port P151 operation mode bit 1: TIN1
10 P152MD 0: P152 R W
Port P152 operation mode bit 1: TIN2
11 P153MD 0: P153 R W
Port P153 operation mode bit 1: TIN3
12 P154MD 0: P154 R W
Port P154 operation mode bit 1: TIN4
13 P155MD 0: P155 R W
Port P155 operation mode bit 1: TIN5
14 P156MD 0: P156 R W
Port P156 operation mode bit 1: TIN6
15 P157MD 0: P157 R W
Port P157 operation mode bit 1: TIN7
P16 Operation Mode Register (P16MOD) <Address: H’0080 0750>
123456b7b0
P164MD P165MD P166MD P167MDP160MD P161MD P162MD P163MD
00000000
<After reset: H’00>
b Bit Name Function R W
0 P160MD 0: P160 R W
Port P160 operation mode bit 1: TO21
1 P161MD 0: P161 R W
Port P161 operation mode bit 1: TO22
2 P162MD 0: P162 R W
Port P162 operation mode bit 1: TO23
3 P163MD 0: P163 R W
Port P163 operation mode bit 1: TO24
4 P164MD 0: P164 R W
Port P164 operation mode bit 1: TO25
5 P165MD 0: P165 R W
Port P165 operation mode bit 1: TO26
6 P166MD 0: P166 R W
Port P166 operation mode bit 1: TO27
7 P167MD 0: P167 R W
Port P167 operation mode bit 1: TO28
