9.2 DMAC Related Registers
The diagram below shows a memory map of the DMAC related registers.
DMAC Related Register Map (1/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0400 DMA0–4 Interrupt Request Status Register DMA0–4 Interrupt Request Mask Register 9-24
(DM04ITST) (DM04ITMK) 9-25
(Use inhibited area)
H'0080 0408 DMA5–9 Interrupt Request Status Register DMA5–9 Interrupt Request Mask Register 9-24
(DM59ITST) (DM59ITMK) 9-25
(Use inhibited area)
H'0080 0410 DMA0 Channel Control Register 0 DMA0 Channel Control Register 1 9-6
(DM0CNT0) (DM0CNT1)
H'0080 0412 DMA0 Source Address Register 9-19
(DM0SA)
H'0080 0414 DMA0 Destination Address Register 9-20
(DM0DA)
H'0080 0416 DMA0 Transfer Count Register 9-21
(DM0TCT)
H'0080 0418 DMA5 Channel Control Register 0 DMA5 Channel Control Register 1 9-11
(DM5CNT0) (DM5CNT1)
H'0080 041A DMA5 Source Address Register 9-19
(DM5SA)
H'0080 041C DMA5 Destination Address Register 9-20
(DM5DA)
H'0080 041E DMA5 Transfer Count Register 9-21
(DM5TCT)
H'0080 0420 DMA1 Channel Control Register 0 DMA1 Channel Control Register 1 9-7
(DM1CNT0) (DM1CNT1)
H'0080 0422 DMA1 Source Address Register 9-19
(DM1SA)
H'0080 0424 DMA1 Destination Address Register 9-20
(DM1DA)
H'0080 0426 DMA1 Transfer Count Register 9-21
(DM1TCT)
H'0080 0428 DMA6 Channel Control Register 0 DMA6 Channel Control Register 1 9-12
(DM6CNT0) (DM6CNT1)
H'0080 042A DMA6 Source Address Register 9-19
(DM6SA)
H'0080 042C DMA6 Destination Address Register 9-20
(DM6DA)
H'0080 042E DMA6 Transfer Count Register 9-21
(DM6TCT)
H'0080 0430 DMA2 Channel Control Register 0 DMA2 Channel Control Register 1 9-8
(DM2CNT0) (DM2CNT1)
H'0080 0432 DMA2 Source Address Register 9-19
(DM2SA)
H'0080 0434 DMA2 Destination Address Register 9-20
(DM2DA)
H'0080 0436 DMA2 Transfer Count Register 9-21
(DM2TCT)
H'0080 0438 DMA7 Channel Control Register 0 DMA7 Channel Control Register 1 9-13
(DM7CNT0) (DM7CNT1)
H'0080 043A DMA7 Source Address Register 9-19
(DM7SA)
H'0080 043C DMA7 Destination Address Register 9-20
(DM7DA)
H'0080 043E DMA7 Transfer Count Register 9-21
(DM7TCT)
