9
DMAC
9-5
32180 Group User’s Manual (Rev.1.0)
9.2 DMAC Related Registers
DMAC Related Register Map (2/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0440 DMA3 Channel Control Register 0 DMA3 Channel Control Register 1 9-9
(DM3CNT0) (DM3CNT1)
H'0080 0442 DMA3 Source Address Register 9-19
(DM3SA)
H'0080 0444 DMA3 Destination Address Register 9-20
(DM3DA)
H'0080 0446 DMA3 Transfer Count Register 9-21
(DM3TCT)
H'0080 0448 DMA8 Channel Control Register 0 DMA8 Channel Control Register 1 9-14
(DM8CNT0) (DM8CNT1)
H'0080 044A DMA8 Source Address Register 9-19
(DM8SA)
H'0080 044C DMA8 Destination Address Register 9-20
(DM8DA)
H'0080 044E DMA8 Transfer Count Register 9-21
(DM8TCT)
H'0080 0450 DMA4 Channel Control Register 0 DMA4 Channel Control Register 1 9-10
(DM4CNT0) (DM4CNT1)
H'0080 0452 DMA4 Source Address Register 9-19
(DM4SA)
H'0080 0454 DMA4 Destination Address Register 9-20
(DM4DA)
H'0080 0456 DMA4 Transfer Count Register 9-21
(DM4TCT)
H'0080 0458 DMA9 Channel Control Register 0 DMA9 Channel Control Register 1 9-15
(DM9CNT0) (DM9CNT1)
H'0080 045A DMA9 Source Address Register 9-19
(DM9SA)
H'0080 045C DMA9 Destination Address Register 9-20
(DM9DA)
H'0080 045E DMA9 Transfer Count Register 9-21
(DM9TCT)
H'0080 0460 DMA0 Software Request Generation Register 9-18
(DM0SRI)
H'0080 0462 DMA1 Software Request Generation Register 9-18
(DM1SRI)
H'0080 0464 DMA2 Software Request Generation Register 9-18
(DM2SRI)
H'0080 0466 DMA3 Software Request Generation Register 9-18
(DM3SRI)
H'0080 0468 DMA4 Software Request Generation Register 9-18
(DM4SRI)
(Use inhibited area)
H'0080 0470 DMA5 Software Request Generation Register 9-18
(DM5SRI)
H'0080 0472 DMA6 Software Request Generation Register 9-18
(DM6SRI)
H'0080 0474 DMA7 Software Request Generation Register 9-18
(DM7SRI)
H'0080 0476 DMA8 Software Request Generation Register 9-18
(DM8SRI)
H'0080 0478 DMA9 Software Request Generation Register 9-18
(DM9SRI)
|
To Next Page
