10-3

MULTIJUNCTION TIMERS

10.1 Outline of Multijunction Timers

32180 Group User’s Manual (Rev.1.0)

Table 10.1.2 Interrupt Generation Functions of MJT

Signal Name MJT Interrupt Request Source Source of Interrupt No. of ICU Input Sources

IRQ0 TIO0–3 output TIO0–3 output interrupt 4

IRQ1 TOP6, TOP7 output TOP6, 7 output interrupt 2

IRQ2 TOP0–5 output TOP0–5 output interrupt 6

IRQ3 TIO8, TIO9 output TIO8, 9 output interrupt 2

IRQ4 TIO4–7 output TIO4–7 output interrupt 4

IRQ5 TOP10 output TOP10 output interrupt 1

IRQ6 TOP8, TOP9 output TOP8, 9 output interrupt 2

IRQ7 TMS0, TMS1 output TMS0, 1 output interrupt 2

IRQ8 TIN7–TIN11 input TIN7–TIN11 input interrupt 5

IRQ9 TIN0–TIN2 input TIN0–2 input interrupt 3

IRQ10 TIN12–TIN19 input TIN12–19 input interrupt 8

IRQ11 TIN20–TIN23 input TIN20–23 input interrupt 4

IRQ12 TIN3–TIN6 input TIN3–6 input interrupt 4

IRQ13 TOU0_0–TOU0_7 output TOU0 output interrupt 8

IRQ14 TID0 output TID0 output interrupt 1

IRQ15 TID1 output TID1 output interrupt 1

IRQ16 TOU1_0–TOU1_7 output, TOU1 + TOU2 output interrupt 16

TOU2_0–TOU2_7 output

IRQ17 TID2 output TID2 output interrupt 1

IRQ18 TIN30–TIN33 input TIN30–TIN33 input interrupt 4

Table 10.1.3 DMA Transfer Request Generation by MJT

Corresponding DMAC Channel No. DMA Transfer Request Source

DMA0 TIO8_udf

Input event bus 2

TID0_udf/ovf
