Renesas M32R/ECU Series User Manual

10
10-4
MULTIJUNCTION TIMERS
10.1 Outline of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
DMA6 TIN1 input signal
TOU0_1irq
Common transfer request source (see Table 10.1.4)
DMA7 TIN2 input signal
TOU0_2irq
Common transfer request source (see Table 10.1.4)
DMA8 Input event bus 0
TIN7 input signal
TOU0_6irq
Common transfer request source (see Table 10.1.4)
DMA9 TIN8 input signal
TOU0_7irq
Common transfer request source (see Table 10.1.4)
Table 10.1.4 DMA Transfer Request Generation by MJT (Common)
Corresponding DMAC Channel No. DMA Transfer Request Source
DMAn Input event bus 1
Input event bus 3
Output event bus 2
Output event bus 3
TIN0 input signal
TIO8_udf
Table 10.1.5 A-D Conversion Start Request by MJT
Signal Name A-D Conversion Start Request Source A-D Converter
AD0TRG Input event bus 2, input event bus 3, Can be input to A-D0 conversion start trigger
output event bus 3, TIN23
AD1TRG Input event bus 2, input event bus 3, Can be input to A-D1 conversion start trigger
TID1udf/ovf, TIN23
