10
10-14
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
Table 10.2.4 Timing at Which Signals are Generated to the Output Event Bus by Each Timer
Timer Mode Timing at which signals are generated to the output event bus
TOP Single-shot output mode When the counter underflows
Delayed single-shot output mode When the counter underflows
Continuous output mode When the counter underflows
TIO(Note 1) Measure clear input mode When the counter underflows
Measure free-run input mode When the counter underflows
Noise processing input mode When the counter underflows
PWM output mode When the counter underflows
Single-shot output mode When the counter underflows
Delayed single-shot output mode When the counter underflows
Continuous output mode When the counter underflows
TMS (16-bit measure input) No signals generated
TML (32-bit measure input) No signals generated
TID Fixed period mode No signals generated
Event count mode No signals generated
Multiply-by-4 event count mode No signals generated
Up/down event count mode No signals generated
TOU PWM output mode No signals generated
Single-shot PWM mode No signals generated
Delayed single-shot output mode No signals generated
Single-shot output mode No signals generated
Continuous output mode No signals generated
Note 1: TIO5–7 output an underflow signal to the input event bus.
