10
10-20
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TLCK Input Processing Control Register (TCLKCR)
<Address: H
’0080 0210>b01234567891011121314b15
TCLK3S TCLK2S TCLK1S
TCLK0S
0
0
000
00
<After reset: H’0000>
b Bit Name Function R W
0, 1 No function assigned. Fix to "0". 00
2, 3 TCLK3S 00: BCLK/2 R W
TCLK3 input processing select bit 01: Rising edge
10: Falling edge
11: Both edges
4 No function assigned. Fix to "0". 00
5–7 TCLK2S 000: Disable input R W
TCLK2 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
8 No function assigned. Fix to "0". 00
9–11 TCLK1S 000: Disable input R W
TCLK1 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
12,13 No function assigned. Fix to "0". 00
14,15 TCLK0S 00: BCLK/2 R W
TCLK0 input processing select bit 01: Rising edge
10: Falling edge
11: Both edges110
Note: • This register must always be accessed in halfwords.
