MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TIN0–4 Input Processing Control Register (TIN04CR) <Address: H’0080 0212>
b01234567891011121314b15
TIN4S TIN
3
S TIN2S TIN0STIN1S
0
000
0
0
0
0
0
0
000000
<After reset: H’0000>
b Bit Name Function R W
0 No function assigned. Fix to "0". 00
1–3 TIN4S 000: Disable input R W
TIN4 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
4 No function assigned. Fix to "0". 00
5–7 TIN3S 000: Disable input R W
TIN3 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
8,9 No function assigned. Fix to "0". 00
10,11 TIN2S 00: Disable input R W
TIN2 input processing select bit 01: Rising edge
10: Falling edge
11: Both edges
12,13 TIN1S 00: Disable input R W
TIN1 input processing select bit 01: Rising edge
10: Falling edge
11: Both edges
14,15 TIN0S 00: Disable input R W
TIN0 input processing select bit 01: Rising edge
10: Falling edge
11: Both edges
Note: • This register must always be accessed in halfwords.
