MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
F/F0–15 Protect Register (FF015P) <Address: H’0080 0224>
b0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 b15
FP15 FP14 FP13 FP12 FP11 FP10 FP9 FP8 FP7 FP6 FP5 FP4 FP3 FP2 FP1 FP0
0000000000000000
<After reset: H’0000>
b Bit Name Function R W
0 FP15 (F/F15 protect bit) 0: Enable write to F/F output bit R W
1 FP14 (F/F14 protect bit) 1: Disable write to F/F output bit
2 FP13 (F/F13 protect bit)
3 FP12 (F/F12 protect bit)
4 FP11 (F/F11 protect bit)
5 FP10 (F/F10 protect bit)
6 FP9 (F/F9 protect bit)
7 FP8 (F/F8 protect bit)
8 FP7 (F/F7 protect bit)
9 FP6 (F/F6 protect bit)
10 FP5 (F/F5 protect bit)
11 FP4 (F/F4 protect bit)
12 FP3 (F/F3 protect bit)
13 FP2 (F/F2 protect bit)
14 FP1 (F/F1 protect bit)
15 FP0 (F/F0 protect bit)
Note: • This register must always be accessed in halfwords.
F/F16–20 Protect Register (FF1620P) <Address: H’0080 0229>
9 1011121314b15b8
FP16FP17FP20 FP19 FP18
00000
<After reset: H’00>
b Bit Name Function R W
8–10 No function assigned. Fix to "0". 00
11 FP20 (F/F20 protect bit) 0: Enable write to F/F output bit R W
12 FP19 (F/F19 protect bit) 1: Disable write to F/F output bit
13 FP18 (F/F18 protect bit)
14 FP17 (F/F17 protect bit)
15 FP16 (F/F16 protect bit)
