10
10-29
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
F/F16–19 Source Select Register (FF1619S) <Address: H’0080 0223>
9 1011121314b15b8
FS16FS17FS19 FS18
00000000
<After reset: H’0000>
b Bit Name Function R W
8, 9 FS19 00: TIO8 output R W
F/F19 source select bit 01: TIO8 output
10: Output event bus 0
11: Output event bus 1
10, 11 FS18 00: TIO7 output R W
F/F18 source select bit 01: TIO7 output
10: Output event bus 0
11: Output event bus 1
12, 13 FS17 00: TIO6 output R W
F/F17 source select bit 01: TIO6 output
10: Output event bus 0
11: Output event bus 1
14, 15 FS16 00: TIO5 output R W
F/F16 source select bit 01: Output event bus 0
10: Output event bus 1
11: Output event bus 3
These registers select the signal source for each output F/F (flip-flop). This signal source can be chosen to be a
signal from the internal output bus or an underflow output from each timer.
