10
10-28
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
F/F6–15 Source Select Register (FF615S) <Address: H’0080 0220>
b0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 b15
FS15 FS14 FS13 FS12 FS11 FS10 FS9 FS8 FS7 FS6
0000000000000
<After reset: H’0000>
b Bit Name Function R W
0–2 No function assigned. Fix to "0". 00
3 FS15 0: TIO4 output R W
F/F15 source select bit 1: Output event bus 0
4 FS14 0: TIO3 output R W
F/F14 source select bit 1: Output event bus 0
5 FS13 0: TIO2 output R W
F/F13 source select bit 1: Output event bus 3
6 FS12 0: TIO1 output R W
F/F12 source select bit 1: Output event bus 2
7 FS11 0: TIO0 output R W
F/F11 source select bit 1: Output event bus 1
8, 9 FS10 00: TOP10 output R W
F/F10 source select bit 01: TOP10 output
10: Output event bus 0
11: Output event bus 1
10, 11 FS9 00: TOP9 output R W
F/F9 source select bit 01: TOP9 output
10: Output event bus 0
11: Output event bus 1
12, 13 FS8 00: TOP8 output R W
F/F8 source select bit 01: Output event bus 0
10: Output event bus 1
11: Output event bus 2
14 FS7 0: TOP7 output R W
F/F7 source select bit 1: Output event bus 0
15 FS6 0: TOP6 output R W
F/F6 source select bit 1: Output event bus 1
Note: • This register must always be accessed in halfwords.
