10
10-32
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
F/F0–15 Data Register (FF015D) <Address: H’0080 0226>
b01234567891011121314b15
FD15 FD14 FD13 FD12 FD11 FD10 FD9 FD8 FD7 FD6 FD5 FD4 FD3 FD2 FD1 FD0
0000000000000000
<After reset: H’0000>
b Bit Name Function R W
0 FD15 (F/F15 output data bit) 0: F/F output data = 0 R W
1 FD14 (F/F14 output data bit) 1: F/F output data = 1
2 FD13 (F/F13 output data bit)
3 FD12 (F/F12 output data bit)
4 FD11 (F/F11 output data bit)
5 FD10 (F/F10 output data bit)
6 FD9 (F/F9 output data bit)
7 FD8 (F/F8 output data bit)
8 FD7 (F/F7 output data bit)
9 FD6 (F/F6 output data bit)
10 FD5 (F/F5 output data bit)
11 FD4 (F/F4 output data bit)
12 FD3 (F/F3 output data bit)
13 FD2 (F/F2 output data bit)
14 FD1 (F/F1 output data bit)
15 FD0 (F/F0 output data bit)
Note: • This register must always be accessed in halfwords.
F/F16–20 Data Register (FF1620D) <Address: H’0080 022B>
9 1011121314b15b8
FD16FD17FD20 FD19 FD18
00000
<After reset: H’00>
b Bit Name Function R W
8–10 No function assigned. Fix to "0". 00
11 FD20 (F/F20 output data bit) 0: F/F output data = 0 R W
12 FD19 (F/F19 output data bit) 1: F/F output data = 1
13 FD18 (F/F18 output data bit)
14 FD17 (F/F17 output data bit)
15 FD16 (F/F16 output data bit)
