10
10-33
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
F/F21–28 Data Register (FF2128D) <Address: H’0080 07D7>
9 1011121314b15b8
FD28FD27FD24 FD25 FD26FD21 FD22 FD23
00000000
<After reset: H’00>
b Bit Name Function R W
8 FD21 (F/F21 output data bit) 0: F/F output data = 0 R W
9 FD22 (F/F22 output data bit) 1: F/F output data = 1
10 FD23 (F/F23 output data bit)
11 FD24 (F/F24 output data bit)
12 FD25 (F/F25 output data bit)
13 FD26 (F/F26 output data bit)
14 FD27 (F/F27 output data bit)
15 FD28 (F/F28 output data bit)
F/F29–36 Data Register (FF2936D) <Address: H’0080 0BD7>
9 1011121314b15b8
FD36FD35FD32 FD33 FD34FD29 FD30 FD31
00000000
<After reset: H’00>
b Bit Name Function R W
8 FD29 (F/F29 output data bit) 0: F/F output data = 0 R W
9 FD30 (F/F30 output data bit) 1: F/F output data = 1
10 FD31 (F/F31 output data bit)
11 FD32 (F/F32 output data bit)
12 FD33 (F/F33 output data bit)
13 FD34 (F/F34 output data bit)
14 FD35 (F/F35 output data bit)
15 FD36 (F/F36 output data bit)
To Next Page
