Renesas M32R/ECU Series User Manual

10
10-49
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TIN7–11 Interrupt Request Status Register (TIN711IST) <Address: H’0080 023A>
123456b7b0
TINIS7TINIS8TINIS9TINIS10TINIS11
00000
0
0
0
<After reset: H’00>
b Bit Name Function R W
0–2 No function assigned. Fix to "0". 00
3 TINIS11 (TIN11 interrupt request status bit) 0: Interrupt not requested R(Note 1)
4 TINIS10 (TIN10 interrupt request status bit) 1: Interrupt requested
5 TINIS9 (TIN9 interrupt request status bit)
6 TINIS8 (TIN8 interrupt request status bit)
7 TINIS7 (TIN7 interrupt request status bit)
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
TIN7–11 Interrupt Request Mask Register (TIN711IMA) <Address: H’0080 023B>
9 1011121314b15b8
TINIM7TINIM8TINIM9TINIM10TINIM11
00000
0
0
0
<After reset: H’00>
b Bit Name Function R W
8–10 No function assigned. Fix to "0". 00
11 TINIM11 (TIN11 interrupt request mask bit) 0: Enable interrupt request R W
12 TINIM10 (TIN10 interrupt request mask bit) 1: Mask (disable) interrupt request
13 TINIM9 (TIN9 interrupt request mask bit)
14 TINIM8 (TIN8 interrupt request mask bit)
15 TINIM7 (TIN7 interrupt request mask bit)
