MULTIJUNCTION TIMERS

10.2 Common Units of Multijunction Timers

32180 Group User’s Manual (Rev.1.0)

TIN7–11 input interrupt request

IRQ8

Data bus

TINIS11

F/F

TINIM11

F/F

b11

TINIS10

F/F

TINIM4

F/F

b12

TINIS9

F/F

TINIM9

F/F

b13

TINIS8

F/F

TINIM8

F/F

b14

TINIS7

F/F

TINIM7

F/F

b15

(Level)

5-source inputs

TIN711IST <H'0080 023A>

TIN711IMA<H'0080 023B>

TIN11edge

TIN10edge

TIN9edge

TIN8edge

TIN7edge

Figure 10.2.14 Block Diagram of TIN7–11 Input Interrupt Request
