Renesas M32R/ECU Series User Manual

10
10-51
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TIN12–19 Interrupt Request Status Register (TIN1219IST) <Address: H’0080 023C>
123456b7b0
TINIS12TINIS13TINIS14TINIS15TINIS16TINIS17TINIS18TINIS19
00000000
<After reset: H’00>
b Bit Name Function R W
0 TINIS19 (TIN19 interrupt request status bit) 0: Interrupt not requested R(Note 1)
1 TINIS18 (TIN18 interrupt request status bit) 1: Interrupt requested
2 TINIS17 (TIN17 interrupt request status bit)
3 TINIS16 (TIN16 interrupt request status bit)
4 TINIS15 (TIN15 interrupt request status bit)
5 TINIS14 (TIN14 interrupt request status bit)
6 TINIS13 (TIN13 interrupt request status bit)
7 TINIS12 (TIN12 interrupt request status bit)
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
TIN12–19 Interrupt Request Mask Register (TIN1219IMA) <Address: H’0080 023D>
9 1011121314b15b8
TINIM12TINIM13TINIM14TINIM15TINIM16TINIM17TINIM18TINIM19
00000000
<After reset: H’00>
b Bit Name Function R W
8 TINIM19 (TIN19 interrupt request mask bit) 0: Enable interrupt request R W
9 TINIM18 (TIN18 interrupt request mask bit) 1: Mask (disable) interrupt request
10 TINIM17 (TIN17 interrupt request mask bit)
11 TINIM16 (TIN16 interrupt request mask bit)
12 TINIM15 (TIN15 interrupt request mask bit)
13 TINIM14 (TIN14 interrupt request mask bit)
14 TINIM13 (TIN13 interrupt request mask bit)
15 TINIM12 (TIN12 interrupt request mask bit)
