Renesas M32R/ECU Series User Manual

10
10-53
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TIN20–23 Interrupt Request Mask & Status Register (TIN2023IMS) <Address: H’0080 023E>
123456b7b0
TINIM20TINIM21TINIM22TINIM23TINIS20TINIS21TINIS22TINIS23
00000000
<After reset: H’00>
b Bit Name Function R W
0 TINIS23 (TIN23 interrupt request status bit) 0: Interrupt not requested R(Note 1)
1 TINIS22 (TIN22 interrupt request status bit) 1: Interrupt requested
2 TINIS21 (TIN21 interrupt request status bit)
3 TINIS20 (TIN20 interrupt request status bit)
4 TINIM23 (TIN23 interrupt request mask bit) 0: Enable interrupt request R W
5 TINIM22 (TIN22 interrupt request mask bit) 1: Mask (disable) interrupt request
6 TINIM21 (TIN21 interrupt request mask bit)
7 TINIM20 (TIN20 interrupt request mask bit)
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
TIN24, 25 Interrupt Request Mask Register (TIN2425IMA) <Address: H’0080 07E2>
b0123456b7
TINIM24 TINIM25
0
0
0
0
0
0
00
<After reset: H’00>
b Bit Name Function R W
0–5 No function assigned. Fix to "0". 00
6 TINIM24 (TIN24 interrupt request mask bit) 0: Enable interrupt request R W
7 TINIM25 (TIN25 interrupt request mask bit) 1: Mask (disable) interrupt request
TIN24, 25 Interrupt Request Status Register (TIN2425IST) <Address: H’0080 023A>
b8 9 10 11 12 13 14 b15
TINIS24 TINIS25
0
0
0
0
0
0
00
<After reset: H’00>
b Bit Name Function R W
8–13 No function assigned. Fix to "0". 00
14 TINIS24 (TIN24 interrupt request status bit) 0: Interrupt not requested R(Note 1)
15 TINIS25 (TIN25 interrupt request status bit) 1: Interrupt requested
