Renesas M32R/ECU Series User Manual

10
10-54
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TIN26, 27 Interrupt Request Mask Register (TIN2627IMA) <Address: H’0080 0BE2>
b0123456b7
TINIM26 TINIM27
0
0
0
0
0
0
00
<After reset: H’00>
b Bit Name Function R W
0–5 No function assigned. Fix to "0". 00
6 TINIM26 (TIN26 interrupt request mask bit) 0: Enable interrupt request R W
7 TINIM27 (TIN27 interrupt request mask bit) 1: Mask (disable) interrupt request
TIN26, 27 Interrupt Request Status Register (TIN2627IST) <Address: H’0080 0BE3>
b8 9 10 11 12 13 14 b15
TINIS26 TINIS27
0
0
0
0
0
0
00
<After reset: H’00>
b Bit Name Function R W
8–13 No function assigned. Fix to "0". 00
14 TINIS26 (TIN26 interrupt request status bit) 0: Interrupt not requested R(Note 1)
15 TINIS27 (TIN27 interrupt request status bit) 1: Interrupt requested
TIN28, 29 Interrupt Request Mask Register (TIN2829IMA) <Address: H’0080 0CE2>
b0123456b7
TINIM2
8
TINIM29
0
0
0
0
0
0
0
0
<After reset: H’00>
b Bit Name Function R W
0–5 No function assigned. Fix to "0". 00
6 TINIM28 (TIN28 interrupt request mask bit) 0: Enable interrupt request R W
7 TINIM29 (TIN29 interrupt request mask bit) 1: Mask (disable) interrupt request
TIN28, 29 Interrupt Request Status Register (TIN2829IST) <Address: H’0080 023A>
b8 9 10 11 12 13 14 b15
TINIS28 TINIS29
0
0
0
0
0
0
00
<After reset: H’00>
b Bit Name Function R W
8–13 No function assigned. Fix to "0". 00
14 TINIS28 (TIN28 interrupt request status bit) 0: Interrupt not requested R(Note 1)
15 TINIS29 (TIN29 interrupt request status bit) 1: Interrupt requested
