10-55

MULTIJUNCTION TIMERS

10.2 Common Units of Multijunction Timers

32180 Group User’s Manual (Rev.1.0)

TIN20–29 input interrupt request

IRQ11

Data bus

b15

TINIS29

F/F

TINIM29

F/F

b14

TINIS28

F/F

TINIM28

F/F

b15

TINIS27

F/F

TINIM27

F/F

b15

TINIS26

F/F

TINIM26

F/F

b15

TINIS25

F/F

TINIM25

F/F

(Level)

10-source inputs

TIN2425IST<H'0080 07E3>

TIN2425IMA<H'0080 07E2>

TIN2627IST<H'0080 0BE3>

TIN2627IMA<H'0080 0BE2>

TIN2829IST<H'0080 0CE3>

TIN2829IMA<H'0080 0CE2>

TIN29edge

TIN28edge

TIN27edge

TIN26edge

TIN25edge

b14

TINIS24

F/F

TINIM24

F/F

TIN24edge

To the remaining 4-input sources in the next page

Figure 10.2.16 Block Diagram of TIN20–29 Input Interrupt Request (1/2)
