MULTIJUNCTION TIMERS

10.2 Common Units of Multijunction Timers

32180 Group User’s Manual (Rev.1.0)

To the preceding page

Data bus

TINIS23

F/F

TINIM23

F/F

TINIS22

F/F

TINIM22

F/F

TINIS21

F/F

TINIM21

F/F

TINIS20

F/F

TINIM20

F/F

4-source inputs

TIN2023IMS <H'0080 023E>

TIN23edge

TIN22edge

TIN21edge

TIN20edge

Figure 10.2.17 Block Diagram of TIN20–29 Input Interrupt Request (2/2)
