MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TOU0 Interrupt Request Mask Register (TOU0IMA) <Address: H’0080 07D2>
123456b7b0
TOU0IM7 TOU0IM6 TOU0IM5 TOU0IM4 TOU0IM3 TOU0IM2 TOU0IM1 TOU0IM0
00000000
<After reset: H’00>
b Bit Name Function R W
0 TOU0IM7 (TOU0_7 interrupt request mask bit) 0: Enable interrupt request R W
1 TOU0IM6 (TOU0_6 interrupt request mask bit) 1: Mask (disable) interrupt request
2 TOU0IM5 (TOU0_5 interrupt request mask bit)
3 TOU0IM4 (TOU0_4 interrupt request mask bit)
4 TOU0IM3 (TOU0_3 interrupt request mask bit)
5 TOU0IM2 (TOU0_2 interrupt request mask bit)
6 TOU0IM1 (TOU0_1 interrupt request mask bit)
7 TOU0IM0 (TOU0_0 interrupt request mask bit)
TOU0 Interrupt Request Status Register (TOU0IST) <Address: H’0080 07D3>
9 1011121314b15b8
TOU0IS7 TOU0IS6 TOU0IS5 TOU0IS4 TOU0IS3 TOU0IS2 TOU0IS1 TOU0IS0
00000000
<After reset: H’00>
b Bit Name Function R W
8 TOU0IS7 (TOU0_7 interrupt request status bit) 0: Interrupt not requested R(Note 1)
9 TOU0IS6 (TOU0_6 interrupt request status bit) 1: Interrupt requested
10 TOU0IS5 (TOU0_5 interrupt request status bit)
11 TOU0IS4 (TOU0_4 interrupt request status bit)
12 TOU0IS3 (TOU0_3 interrupt request status bit)
13 TOU0IS2 (TOU0_2 interrupt request status bit)
14 TOU0IS1 (TOU0_1 interrupt request status bit)
15 TOU0IS0 (TOU0_0 interrupt request status bit)
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
