Renesas M32R/ECU Series User Manual

10
10-60
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TOU1 Interrupt Request Mask Register (TOU1IMA) <Address: H’0080 0BD2>
123456b7b0
TOU1IM7 TOU1IM6 TOU1IM5 TOU1IM4 TOU1IM3 TOU1IM2 TOU1IM1 TOU1IM0
00000000
<After reset: H’00>
b Bit Name Function R W
0 TOU1IM7 (TOU1_7 interrupt request mask bit) 0: Enable interrupt request R W
1 TOU1IM6 (TOU1_6 interrupt request mask bit) 1: Mask (disable) interrupt request
2 TOU1IM5 (TOU1_5 interrupt request mask bit)
3 TOU1IM4 (TOU1_4 interrupt request mask bit)
4 TOU1IM3 (TOU1_3 interrupt request mask bit)
5 TOU1IM2 (TOU1_2 interrupt request mask bit)
6 TOU1IM1 (TOU1_1 interrupt request mask bit)
7 TOU1IM0 (TOU1_0 interrupt request mask bit)
TOU1 Interrupt Request Status Register (TOU1IST) <Address: H’0080 0BD3>
9 1011121314b15b8
TOU1IS7 TOU1IS6 TOU1IS5 TOU1IS4 TOU1IS3 TOU1IS2 TOU1IS1 TOU1IS0
00000000
<After reset: H’00>
b Bit Name Function R W
8 TOU1IS7 (TOU1_7 interrupt request status bit) 0: Interrupt not requested R(Note 1)
9 TOU1IS6 (TOU1_6 interrupt request status bit) 1: Interrupt requested
10 TOU1IS5 (TOU1_5 interrupt request status bit)
11 TOU1IS4 (TOU1_4 interrupt request status bit)
12 TOU1IS3 (TOU1_3 interrupt request status bit)
13 TOU1IS2 (TOU1_2 interrupt request status bit)
14 TOU1IS1 (TOU1_1 interrupt request status bit)
15 TOU1IS0 (TOU1_0 interrupt request status bit)
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
