Renesas M32R/ECU Series User Manual

10
10-61
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TOU2 Interrupt Request Mask Register (TOU2IMA) <Address: H’0080 0CD2>
123456b7b0
TOU2IM7 TOU2IM6 TOU2IM5 TOU2IM4 TOU2IM3 TOU2IM2 TOU2IM1 TOU2IM0
00000000
<After reset: H’00>
b Bit Name Function R W
0 TOU2IM7 (TOU2_7 interrupt request mask bit) 0: Enable interrupt request R W
1 TOU2IM6 (TOU2_6 interrupt request mask bit) 1: Mask (disable) interrupt request
2 TOU2IM5 (TOU2_5 interrupt request mask bit)
3 TOU2IM4 (TOU2_4 interrupt request mask bit)
4 TOU2IM3 (TOU2_3 interrupt request mask bit)
5 TOU2IM2 (TOU2_2 interrupt request mask bit)
6 TOU2IM1 (TOU2_1 interrupt request mask bit)
7 TOU2IM0 (TOU2_0 interrupt request mask bit)
TOU2 Interrupt Request Status Register (TOU2IST) <Address: H’0080 0CD3>
9 1011121314b15b8
TOU2IS7 TOU2IS6 TOU2IS5 TOU2IS4 TOU2IS3 TOU2IS2 TOU2IS1 TOU2IS0
00000000
<After reset: H’00>
b Bit Name Function R W
8 TOU2IS7 (TOU2_7 interrupt request status bit) 0: Interrupt not requested R(Note 1)
9 TOU2IS6 (TOU2_6 interrupt request status bit) 1: Interrupt requested
10 TOU2IS5 (TOU2_5 interrupt request status bit)
11 TOU2IS4 (TOU2_4 interrupt request status bit)
12 TOU2IS3 (TOU2_3 interrupt request status bit)
13 TOU2IS2 (TOU2_2 interrupt request status bit)
14 TOU2IS1 (TOU2_1 interrupt request status bit)
15 TOU2IS0 (TOU2_0 interrupt request status bit)
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
