32180 Group User’s Manual (Rev.1.0)
1.4 Pin Assignments
The pins directed for input go to a high-impedance state (Hi-z) when reset. The term “when reset” means that
input on RESET# pin is held low (the device remains reset), and that the RESET# pin is released back high
(the device comes out of reset).
Table 1.4.1 Pin Assignments of the M32180F8VFP/TFP (1/6)
Note 1: The JTCK, JTDI, JTDO and JTMS pins are reset by input from the JTRST pin, and not reset from the RESET# pin.
Pin State When Reset
Port
Other than
port
Other than
port
Function Type
State during
reset
State at reset
release
1 AVCC1 - AVCC1 - - AVCC1 - - -
2 VSS - VSS - - VSS - - -
3 VCCE - VCCE - - VCCE - - -
4 P150/TIN0 P150 TIN0 - Input/output P150 Input Hi-z Hi-z
5 P151/TIN1 P151 TIN1 - Input/output P151 Input Hi-z Hi-z
6 P152/TIN2 P152 TIN2 - Input/output P152 Input Hi-z Hi-z
7 P153/TIN3 P153 TIN3 - Input/output P153 Input Hi-z Hi-z
8 P154/TIN4 P154 TIN4 - Input/output P154 Input Hi-z Hi-z
9 P155/TIN5 P155 TIN5 - Input/output P155 Input Hi-z Hi-z
10 P156/TIN6 P156 TIN6 - Input/output P156 Input Hi-z Hi-z
11 P157/TIN7 P157 TIN7 - Input/output P157 Input Hi-z Hi-z
12 P200/TXD4 P200 TXD4 - Input/output P200 Input Hi-z Hi-z
13 P201/RXD4 P201 RXD4 - Input/output P201 Input Hi-z Hi-z
14 P202/TXD5 P202 TXD5 - Input/output P202 Input Hi-z Hi-z
15 P203/RXD5 P203 RXD5 - Input/output P203 Input Hi-z Hi-z
16 P130/TIN16/PWMOFF0 P130
TIN16/
PWMOFF0
- Input/output P130 Input Hi-z Hi-z
17 P131/TIN17/PWMOFF1 P131
TIN17/
PWMOFF1
- Input/output P131 Input Hi-z Hi-z
18 P132/TIN18 P132 TIN18 - Input/output P132 Input Hi-z Hi-z
19 P133/TIN19 P133 TIN19 - Input/output P133 Input Hi-z Hi-z
20 P134/TIN20 P134 TIN20 - Input/output P134 Input Hi-z Hi-z
21 P135/TIN21 P135 TIN21 - Input/output P135 Input Hi-z Hi-z
22 P136/TIN22 P136 TIN22 - Input/output P136 Input Hi-z Hi-z
23 P137/TIN23 P137 TIN23 - Input/output P137 Input Hi-z Hi-z
24 P220/CTX0 P220 CTX0 - Input/output P220 Input Hi-z Hi-z
25 P221/CRX0 P221 CRX0 - Input P221 Input Hi-z Hi-z
26 P222/CTX1 P222 CTX1 - Input/output P222 Input Hi-z Hi-z
27 P223/CRX1 P223 CRX1 - Input P223 Input Hi-z Hi-z
28 VCCE - VCCE - - VCCE - - -
29 OSC-VSS - OSC-VSS - - OSC-VSS - - -
30 VCNT - VCNT - - VCNT - - -
31 OSC-VCC - OSC-VCC - - OSC-VCC - - -
32 XIN - XIN - Input XIN Input - -
33 OSC-VSS - OSC-VSS - - OSC-VSS - - -
34 XOUT - XOUT - Output XOUT Output XOUT XOUT
35 RESET# - RESET# - Input RESET# Input Hi-z Hi-z
36 P180/TO29 P180 TO29 - Input/output P180 Input Hi-z Hi-z
37 P181/TO30 P181 TO30 - Input/output P181 Input Hi-z Hi-z
38 P182/TO31 P182 TO31 - Input/output P182 Input Hi-z Hi-z
39 P183/TO32 P183 TO32 - Input/output P183 Input Hi-z Hi-z
40 P184/TO33 P184 TO33 - Input/output P184 Input Hi-z Hi-z
41 P185/TO34 P185 TO34 - Input/output P185 Input Hi-z Hi-z
42 P186/TO35 P186 TO35 - Input/output P186 Input Hi-z Hi-z
43 P187/TO36 P187 TO36 - Input/output P187 Input Hi-z Hi-z
44 P74/RTDTXD P74 RTDTXD - Input/output P74 Input Hi-z Hi-z
45 P75/RTDRXD P75 RTDRXD - Input/output P75 Input Hi-z Hi-z
46 P76/RTDACK P76 RTDACK - Input/output P76 Input Hi-z Hi-z
47 P77/RTDCLK P77 RTDCLK - Input/output P77 Input Hi-z Hi-z
48 JTDI (Note 1) - JTDI - Input JTDI Input Hi-z Hi-z
49 JTDO (Note 1) - JTDO - Output JTDO Output Hi-z Hi-z
50 JTRST (Note 1) - JTRST - Input JTRST Input Hi-z Hi-z
