Renesas M32R/ECU Series User Manual

1-16
1
OVERVIEW
32180 Group User’s Manual (Rev.1.0)
1.4 Pin Assignments
Pin State When Reset
Port
Other than
port
Other than
port
Function Type
State during
reset
State at reset
release
51 JTCK (Note 1) - JTCK - Input JTCK Input Hi-z Hi-z
52 JTMS (Note 1) - JTMS - Input JTMS Input Hi-z Hi-z
53 P100/TO8 P100 TO8 - Input/output P100 Input Hi-z Hi-z
54 P101/TO9/TXD3 P101 TO9 TXD3 Input/output P101 Input Hi-z Hi-z
55 P102/TO10/CTX1 P102 TO10 CTX1 Input/output P102 Input Hi-z Hi-z
56 P103/TO11 P103 TO11 - Input/output P103 Input Hi-z Hi-z
57 P104/TO12 P104 TO12 - Input/output P104 Input Hi-z Hi-z
58 P105/TO13 P105 TO13 - Input/output P105 Input Hi-z Hi-z
59 P106/TO14 P106 TO14 - Input/output P106 Input Hi-z Hi-z
60 P107/TO15 P107 TO15 - Input/output P107 Input Hi-z Hi-z
61 VCCE - VCCE - - VCCE - - -
62 VSS - VSS - - VSS - - -
63 AVCC0 - AVCC0 - - AVCC0 - - -
64 VREF0 - VREF0 - - VREF0 - - -
65 AD0IN0 - AD0IN0 - Input AD0IN0 Input Hi-z Hi-z
66 AD0IN1 - AD0IN1 - Input AD0IN1 Input Hi-z Hi-z
67 AD0IN2 - AD0IN2 - Input AD0IN2 Input Hi-z Hi-z
68 AD0IN3 - AD0IN3 - Input AD0IN3 Input Hi-z Hi-z
69 AD0IN4 - AD0IN4 - Input AD0IN4 Input Hi-z Hi-z
70 AD0IN5 - AD0IN5 - Input AD0IN5 Input Hi-z Hi-z
71 AD0IN6 - AD0IN6 - Input AD0IN6 Input Hi-z Hi-z
72 AD0IN7 - AD0IN7 - Input AD0IN7 Input Hi-z Hi-z
73 AVSS0 - AVSS0 - - AVSS0 - - -
74 AD0IN8 - AD0IN8 - Input AD0IN8 Input Hi-z Hi-z
75 AD0IN9 - AD0IN9 - Input AD0IN9 Input Hi-z Hi-z
76 AD0IN10 - AD0IN10 - Input AD0IN10 Input Hi-z Hi-z
77 AD0IN11 - AD0IN11 - Input AD0IN11 Input Hi-z Hi-z
78 AD0IN12 - AD0IN12 - Input AD0IN12 Input Hi-z Hi-z
79 AD0IN13 - AD0IN13 - Input AD0IN13 Input Hi-z Hi-z
80 AD0IN14 - AD0IN14 - Input AD0IN14 Input Hi-z Hi-z
81 AD0IN15 - AD0IN15 - Input AD0IN15 Input Hi-z Hi-z
82 P61 P61 - - Input/output P61 Input Hi-z Hi-z
83 P62 P62 - - Input/output P62 Input Hi-z Hi-z
84 P63 P63 - - Input/output P63 Input Hi-z Hi-z
85 SBI# - SBI# - Input SBI# Input Hi-z Hi-z
86 VSS - VSS - - VSS - - -
87 VSS - VSS - - VSS - - -
88 VSS - VSS - - VSS - - -
89 VCCE - VCCE - - VCCE - - -
90 VSS - VSS - - VSS - - -
91 EXCVCC - EXCVCC - - EXCVCC - - -
92 P124/TCLK0 P124 TCLK0 - Input/output P124 Input Hi-z Hi-z
93 P125/TCLK1 P125 TCLK1 - Input/output P125 Input Hi-z Hi-z
94 P126/TCLK2 P126 TCLK2 - Input/output P126 Input Hi-z Hi-z
95 P127/TCLK3 P127 TCLK3 - Input/output P127 Input Hi-z Hi-z
96 P190/TIN26 P190 TIN26 - Input/output P190 Input Hi-z Hi-z
97 P191/TIN27 P191 TIN27 - Input/output P191 Input Hi-z Hi-z
98 P192/TIN28 P192 TIN28 - Input/output P192 Input Hi-z Hi-z
99 P193/TIN29 P193 TIN29 - Input/output P193 Input Hi-z Hi-z
100 P194/TIN30 P194 TIN30 - Input/output P194 Input Hi-z Hi-z
Condition
Pin
No.
Function
Symbol Type
Table 1.4.1 Pin Assignments of the M32180F8VFP/TFP (2/6)
Note 1: The JTCK, JTDI, JTDO and JTMS pins are reset by input from the JTRST pin, and not reset from the RESET# pin.
