Renesas M32R/ECU Series User Manual

1
1-17
OVERVIEW
32180 Group User’s Manual (Rev.1.0)
1.4 Pin Assignments
Table 1.4.1 Pin Assignments of the M32180F8VFP/TFP (3/6)
Pin State When Reset
Port
Other than
port
Other than
port
Function Type
State during
reset
State at reset
release
101 P195/TIN31 P195 TIN31 - Input/output P195 Input Hi-z Hi-z
102 P196/TIN32 P196 TIN32 - Input/output P196 Input Hi-z Hi-z
103 P197/TIN33/PWMOFF2 P197
TIN33/
PWMOFF2
- Input/output P197 Input Hi-z Hi-z
104 P140/TIN8 P140 TIN8 - Input/output P140 Input Hi-z Hi-z
105 P141/TIN9 P141 TIN9 - Input/output P141 Input Hi-z Hi-z
106 P142/TIN10 P142 TIN10 - Input/output P142 Input Hi-z Hi-z
107 P143/TIN11 P143 TIN11 - Input/output P143 Input Hi-z Hi-z
108 P144/TIN12 P144 TIN12 - Input/output P144 Input Hi-z Hi-z
109 P145/TIN13 P145 TIN13 - Input/output P145 Input Hi-z Hi-z
110 P146/TIN14 P146 TIN14 - Input/output P146 Input Hi-z Hi-z
111 P147/TIN15 P147 TIN15 - Input/output P147 Input Hi-z Hi-z
112 P110/TO0 P110 TO0 - Input/output P110 Input Hi-z Hi-z
113 P111/TO1 P111 TO1 - Input/output P111 Input Hi-z Hi-z
114 P112/TO2 P112 TO2 - Input/output P112 Input Hi-z Hi-z
115 P113/TO3 P113 TO3 - Input/output P113 Input Hi-z Hi-z
116 P114/TO4 P114 TO4 - Input/output P114 Input Hi-z Hi-z
117 P115/TO5 P115 TO5 - Input/output P115 Input Hi-z Hi-z
118 P116/TO6 P116 TO6 - Input/output P116 Input Hi-z Hi-z
119 P117/TO7 P117 TO7 - Input/output P117 Input Hi-z Hi-z
120 P97/TO20 P97 TO20 - Input/output P97 Input Hi-z Hi-z
121 P96/TO19 P96 TO19 - Input/output P96 Input Hi-z Hi-z
122 P95/TO18 P95 TO18 - Input/output P95 Input Hi-z Hi-z
123 P94/TO17 P94 TO17 - Input/output P94 Input Hi-z Hi-z
124 P93/TO16 P93 TO16 - Input/output P93 Input Hi-z Hi-z
125 VCCE - VCCE - - VCCE - - -
126 VSS - VSS - - VSS - - -
127 VCC-BUS - VCC-BUS - - VCC-BUS - - -
During single-chip and
external extension modes
P27 Input Hi-z Hi-z
During processor mode A30 Output Hi-z Undefined
During single-chip and
external extension modes
P26 Input Hi-z Hi-z
During processor mode A29 Output Hi-z Undefined
During single-chip and
external extension modes
P25 Input Hi-z Hi-z
During processor mode A28 Output Hi-z Undefined
During single-chip and
external extension modes
P24 Input Hi-z Hi-z
During processor mode A27 Output Hi-z Undefined
During single-chip and
external extension modes
P23 Input Hi-z Hi-z
During processor mode A26 Output Hi-z Undefined
During single-chip and
external extension modes
P22 Input Hi-z Hi-z
During processor mode A25 Output Hi-z Undefined
During single-chip and
external extension modes
P21 Input Hi-z Hi-z
During processor mode A24 Output Hi-z Undefined
During single-chip and
external extension modes
P20 Input Hi-z Hi-z
During processor mode A23 Output Hi-z Undefined
136 VSS - VSS - - VSS - - -
During single-chip and
external extension modes
P37 Input Hi-z Hi-z
During processor mode A22 Output Hi-z Undefined
During single-chip and
external extension modes
P36 Input Hi-z Hi-z
During processor mode A21 Output Hi-z Undefined
During single-chip and
external extension modes
P35 Input Hi-z Hi-z
During processor mode A20 Output Hi-z Undefined
130
Input/output
138
- Input/output
P24
133 P22/A25 P22
P25P25/A28
Function
Type Condition
-
P27 A30
P26 A29
-
128
129
Symbol
Pin
No.
P27/A30
P26/A29
Input/output
- Input/output
A28
- Input/output
131 P24/A27
132 P23/A26 P23 A26
A27
134 P21/A24 P21 A24
A23
- Input/output
- Input/output
- Input/output
A25
-
- Input/output
135 P20/A23
137 P37/A22 P37 A22
P20
Input/output
- Input/output139 P35/A20 P35 A20
P36/A21 P36 A21
