10.4 TIO (Input/Output-Related 16-Bit Timer)
MULTIJUNCTION TIMERS
32180 Group User’s Manual (Rev.1.0)
TIO4 Control Register (TIO4CR)
<Address: H
’0080 034A>123456b7b0
TIO4MTIO4EENTIO4CKS TIO34ENS
00000000
<After reset: H’0000>
b Bit Name Function R W
0, 1 TIO4CKS 00: Clock bus 3 R W
TIO4 clock source select bit 01: Clock bus 1
10: Clock bus 2
11: Clock bus 3
2 TIO4EEN (Note 1) 0: Disable external input R W
TIO4 external input enable bit 1: Enable external input
3, 4 TIO34ENS 00: External input TIN6 R W
TIO3,4 enable/measure input source select bit 01: – ditto –
10: Input event bus 2
11: Input event bus 3
5–7 TIO4M 000: Single-shot output mode R W
TIO4 operation mode select bit 001: Delayed single-shot output mode
010: Continuous output mode
011: PWM output mode
100: Measure clear input mode
101: Measure free-run input mode
110: Noise processing input mode
111: – ditto –
Note 1: During measure free-run/clear input mode, even if this bit is set to "0" (external input disabled), when a capture signal is
entered from an external device, the counter value at that point in time is written into the measure register. In measure clear
input mode, however, if this bit = "0" (external input disabled), the counter value is not initialized (H’FFFF) upon capture
and, therefore, this bit should be set to "1" (external input enabled) when using measure clear input mode.
Note: • Operation mode can only be set or changed while the counter is inactive.
