10-105

10.4 TIO (Input/Output-Related 16-Bit Timer)

MULTIJUNCTION TIMERS

32180 Group User’s Manual (Rev.1.0)

clk

en/cap

TCLK2S

TIN8S

Clock bus Input event bus

3 2 1 0

TIN7 (P157)

TCLK1 (P125)

clk

en/cap

TIO 5

TCLK1S

TIN7S

TIN8 (P140)

TCLK2 (P126)

TIO 6

TIN9 (P141)

clk

en/cap

TIO 7

TIN9S

TIN10 (P142)

TIN10S

clk

en/cap

TIO 8

clk

en/cap

TIO 9

TIN11 (P143)

TIN11S

: Selector

3 2 1 0

Note: • This diagram only illustrates TIO control registers and is partly omitted.

Figure 10.4.4 Outline Diagram of TIO5–9 Clock and Enable Inputs
