10
10-108
10.4 TIO (Input/Output-Related 16-Bit Timer)
MULTIJUNCTION TIMERS
32180 Group User’s Manual (Rev.1.0)
TIO7 Control Register (TIO7CR)
<Address: H
’0080 036B>9 1011121314b15b8
TIO7MTIO7CKS TIO7ENS
0000000
<After reset: H’00>
b Bit Name Function R W
8 No function assigned. Fix to "0". 00
9, 10 TIO7CKS 00: Clock bus 0 R W
TIO7 clock source select bit 01: Clock bus 1
10: Clock bus 2
11: Clock bus 3
11, 12 TIO7ENS 00: No selection R W
TIO7 enable/measure input source select bit 01: External input TIN9
10: Input event bus 0
11: Input event bus 3
13–15 TIO7M 000: Single-shot output mode R W
TIO7 operation mode select bit 001: Delayed single-shot output mode
010: Continuous output mode
011: PWM output mode
100: Measure clear input mode
101: Measure free-run input mode
110: Noise processing input mode
111: – ditto –
Note: • Operation mode can only be set or changed while the counter is inactive.
TIO8 Control Register (TIO8CR)
<Address: H
’0080 038A>123456b7b0
TIO8MTIO8CKS TIO8ENS
00000000
<After reset: H’00>
b Bit Name Function R W
0, 1 TIO8CKS 100: Clock bus 0 R W
TIO8 clock source select bit 101: Clock bus 1
110: Clock bus 2
111: Clock bus 3
2–4 TIO8ENS 000: No selection R W
TIO8 enable/measure input source select bit 001: – ditto –
010: – ditto –
011: – ditto –
100: External input TIN10
101: Input event bus 1
110: Input event bus 2
111: Input event bus 3
5–7 TIO8M 000: Single-shot output mode R W
TIO8 operation mode select bit 001: Delayed single-shot output mode
010: Continuous output mode
011: PWM output mode
100: Measure clear input mode
101: Measure free-run input mode
110: Noise processing input mode
111: – ditto –
Note: • Operation mode can only be set or changed while the counter is inactive.
