10-107
10
10.4 TIO (Input/Output-Related 16-Bit Timer)
MULTIJUNCTION TIMERS
32180 Group Users Manual (Rev.1.0)
TIO6 Control Register (TIO6CR) <Address: H0080 036A>
123456D7D0
TIO6MTIO6CKS TIO6ENS
00000000
<After reset: H00>
b Bit Name Function R W
0–2 TIO6CKS 000: External input TCLK2 R W
TIO6 clock source select bit 001: ditto
010: ditto
011: ditto
100: Clock bus 0
101: Clock bus 1
110: Clock bus 2
111: Clock bus 3
3, 4 TIO6ENS 00: No selection R W
TIO6 enable/measure input source select bit 01: External input TIN8
10: Input event bus 2
11: Input event bus 3
5–7 TIO6M 000: Single-shot output mode R W
TIO6 operation mode select bit 001: Delayed single-shot output mode
010: Continuous output mode
011: PWM output mode
100: Measure clear input mode
101: Measure free-run input mode
110: Noise processing input mode
111: ditto
Note: Operation mode can only be set or changed while the counter is inactive.
