10
10-155
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
TOU Related Register Map (2/4)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 07C8 TOU0_7 Counter (Upper) 10-161
(TOU07CTW) (TOU07CTH)
H'0080 07CA (Lower) 10-163
(TOU07CT)
H'0080 07CC TOU0_7 Reload Register TOU0_7 Reload 1 Register 10-164
(TOU07RLW) (TOU07RL1) 10-167
H'0080 07CE TOU0_7 Reload 0 Register 10-166
(TOU07RL0)
H'0080 07D2 TOU0 Interrupt Request Mask Register TOU0 Interrupt Request Status Register 10-58
(TOU0IMA) (TOU0IST)
H'0080 07D8 TOU0 Control Register 1 10-158
(TOU0CR1)
H'0080 07DA TOU0 Control Register 0 10-158
(TOU0CR0)
H'0080 07DC (Use inhibited area) TOU0 Enable Protect Register 10-168
(TOU0PRO)
H'0080 07DE (Use inhibited area) TOU0 Count Enable Register 10-169
(TOU0CEN)
H'0080 07E0 PWMOFF0 Input Processing Control Register 10-171
(PWMOFF0CR)
H'0080 0B90 TOU1_0 Counter (Upper) 10-161
(TOU10CTW) (TOU10CTH)
H'0080 0B92 (Lower) 10-163
(TOU10CT)
H'0080 0B94 TOU1_0 Reload Register TOU1_0 Reload 1 Register 10-164
(TOU10RLW) (TOU10RL1) 10-167
H'0080 0B96 TOU1_0 Reload 0 Register 10-166
(TOU10RL0)
H'0080 0B98 TOU1_1 Counter (Upper) 10-161
(TOU11CTW) (TOU11CTH)
H'0080 0B9A (Lower) 10-163
(TOU11CT)
H'0080 0B9C TOU1_1 Reload Register TOU1_1 Reload 1 Register 10-164
(TOU11RLW) (TOU11RL1) 10-167
H'0080 0B9E TOU1_1 Reload 0 Register 10-166
(TOU11RL0)
H'0080 0BA0 TOU1_2 Counter (Upper) 10-161
(TOU12CTW) (TOU12CTH)
H'0080 0BA2 (Lower) 10-163
(TOU12CT)
H'0080 0BA4 TOU1_2 Reload Register TOU1_2 Reload 1 Register 10-164
(TOU12RLW) (TOU12RL1) 10-167
H'0080 0BA6 TOU1_2 Reload 0 Register 10-166
(TOU12RL0)
H'0080 0BA8 TOU1_3 Counter (Upper) 10-161
(TOU13CTW) (TOU13CTH)
H'0080 0BAA (Lower) 10-163
(TOU13CT)
H'0080 0BAC TOU1_3 Reload Register TOU1_3 Reload 1 Register 10-164
(TOU13RLW) (TOU13RL1) 10-167
H'0080 0BAE TOU1_3 Reload 0 Register 10-166
(TOU13RL0)
H'0080 0BB0 TOU1_4 Counter (Upper) 10-161
(TOU14CTW) (TOU14CTH)
H'0080 0BB2 (Lower) 10-163
(TOU14CT)
H'0080 0BB4 TOU1_4 Reload Register TOU1_4 Reload 1 Register 10-164
(TOU14RLW) (TOU14RL1) 10-167
H'0080 0BB6 TOU1_4 Reload 0 Register 10-166
(TOU14RL0)
|
|
|
To Next Page
