10
10-156
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
TOU Related Register Map (3/4)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0BB8 TOU1_5 Counter (Upper) 10-161
(TOU15CTW) (TOU15CTH)
H'0080 0BBA (Lower) 10-163
(TOU15CT)
H'0080 0BBC TOU1_5 Reload Register TOU1_5 Reload 1 Register 10-164
(TOU15RLW) (TOU15RL1) 10-167
H'0080 0BBE TOU1_5 Reload 0 Register 10-166
(TOU15RL0)
H'0080 0BC0 TOU1_6 Counter (Upper) 10-161
(TOU16CTW) (TOU16CTH)
H'0080 0BC2 (Lower) 10-163
(TOU16CT)
H'0080 0BC4 TOU1_6 Reload Register TOU1_6 Reload 1 Register 10-164
(TOU16RLW) (TOU16RL1) 10-167
H'0080 0BC6 TOU1_6 Reload 0 Register 10-166
(TOU16RL0)
H'0080 0BC8 TOU1_7 Counter (Upper) 10-161
(TOU17CTW) (TOU17CTH)
H'0080 0BCA (Lower) 10-163
(TOU17CT)
H'0080 0BCC TOU1_7 Reload Register TOU1_7 Reload 1 Register 10-164
(TOU17RLW) (TOU17RL1) 10-167
H'0080 0BCE TOU1_7 Reload 0 Register 10-166
(TOU17RL0)
H'0080 0BD2 TOU1 Interrupt Request Mask Register TOU1 Interrupt Request Status Register 10-60
(TOU1IMA) (TOU1IST)
H'0080 0BD8 TOU1 Control Register 1 10-159
(TOU1CR1)
H'0080 0BDA TOU1 Control Register 0 10-159
(TOU1CR0)
H'0080 0BDC (Use inhibited area) TOU1 Enable Protect Register 10-168
(TOU1PRO)
H'0080 0BDE (Use inhibited area) TOU1 Count Enable Register 10-169
(TOU1CEN)
H'0080 0BE0 PWMOFF1 Input Processing Control Register 10-171
(PWMOFF1CR)
H'0080 0C90 TOU2_0 Counter (Upper) 10-161
(TOU20CTW) (TOU20CTH)
H'0080 0C92 (Lower) 10-163
(TOU20CT)
H'0080 0C94 TOU2_0 Reload Register TOU2_0 Reload 1 Register 10-164
(TOU20RLW) (TOU20RL1) 10-167
H'0080 0C96 TOU2_0 Reload 0 Register 10-166
(TOU20RL0)
H'0080 0C98 TOU2_1 Counter (Upper) 10-161
(TOU21CTW) (TOU21CTH)
H'0080 0C9A (Lower) 10-163
(TOU21CT)
H'0080 0C9C TOU2_1 Reload Register TOU2_1 Reload 1 Register 10-164
(TOU21RLW) (TOU21RL1) 10-167
H'0080 0C9E TOU2_1 Reload 0 Register 10-166
(TOU21RL0)
H'0080 0CA0 TOU2_2 Counter (Upper) 10-161
(TOU22CTW) (TOU22CTH)
H'0080 0CA2 (Lower) 10-163
(TOU22CT)
H'0080 0CA4 TOU2_2 Reload Register TOU2_2 Reload 1 Register 10-164
(TOU22RLW) (TOU22RL1) 10-167
H'0080 0CA6 TOU2_2 Reload 0 Register 10-166
(TOU22RL0)
|
|
|
To Next Page
