10
10-157
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
TOU Related Register Map (4/4)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0CA8 TOU2_3 Counter (Upper) 10-161
(TOU23CTW) (TOU23CTH)
H'0080 0CAA (Lower) 10-163
(TOU23CT)
H'0080 0CAC TOU2_3 Reload Register TOU2_3 Reload 1 Register 10-164
(TOU23RLW) (TOU23RL1) 10-167
H'0080 0CAE TOU2_3 Reload 0 Register 10-166
(TOU23RL0)
H'0080 0CB0 TOU2_4 Counter (Upper) 10-161
(TOU24CTW) (TOU24CTH)
H'0080 0CB2 (Lower) 10-163
(TOU24CT)
H'0080 0CB4 TOU2_4 Reload Register TOU2_4 Reload 1 Register 10-164
(TOU24RLW) (TOU24RL1) 10-167
H'0080 0CB6 TOU2_4 Reload 0 Register 10-166
(TOU24RL0)
H'0080 0CB8 TOU2_5 Counter (Upper) 10-161
(TOU25CTW) (TOU25CTH)
H'0080 0CBA (Lower) 10-163
(TOU25CT)
H'0080 0CBC TOU2_5 Reload Register TOU2_5 Reload 1 Register 10-164
(TOU25RLW) (TOU25RL1) 10-167
H'0080 0CBE TOU2_5 Reload 0 Register 10-166
(TOU25RL0)
H'0080 0CC0 TOU2_6 Counter (Upper) 10-161
(TOU26CTW) (TOU26CTH)
H'0080 0CC2 (Lower) 10-163
(TOU26CT)
H'0080 0CC4 TOU2_6 Reload Register TOU2_6 Reload 1 Register 10-164
(TOU26RLW) (TOU26RL1) 10-167
H'0080 0CC6 TOU2_6 Reload 0 Register 10-166
(TOU26RL0)
H'0080 0CC8 TOU2_7 Counter (Upper) 10-161
(TOU27CTW) (TOU27CTH)
H'0080 0CCA (Lower) 10-163
(TOU27CT)
H'0080 0CCC TOU2_7 Reload Register TOU2_7 Reload 1 Register 10-164
(TOU27RLW) (TOU27RL1) 10-167
H'0080 0CCE TOU2_7 Reload 0 Register 10-166
(TOU27RL0)
H'0080 0CD2 TOU2 Interrupt Request Mask Register TOU2 Interrupt Request Status Register 10-61
(TOU2IMA) (TOU2IST)
H'0080 0CD8 TOU2 Control Register 1 10-160
(TOU2CR1)
H'0080 0CDA TOU2 Control Register 0 10-160
(TOU2CR0)
H'0080 0CDC (Use inhibited area) TOU2 Enable Protect Register 10-168
(TOU2PRO)
H'0080 0CDE (Use inhibited area) TOU2 Count Enable Register 10-169
(TOU2CEN)
H'0080 0CE0 PWMOFF2 Input Processing Control Register 10-172
(PWMOFF2CR)
|
|
To Next Page
