10
10-196
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
Figure 10.8.20 Typical Operation in Single-shot PWM Output Mode (Reload 1 Register: H’FFFF)
H'FFFF
H'0000
H'E000
H'E000
H'(FFFF-1)
H'FFFF
Because the reload 1 register = H'FFFF,
a superficial underflow is generated
Enabled
(by writing to the enable bit
or by external input)
Note 1: DMA transfer request also is generated with the same timing.
Note: • This diagram does not show detailed timing information.
Counter
Undefined
value
Enable bit
Reload 0 register
Reload 1 register
F/F output
Interrupt request
due to underflow
(Note 1)
Timing at which startup requests to other timers are generated
Count clock
Count down from
the reload 0
register set value
Underflow
Superficial
underflow
Data not inverted
To Next Page
