11
11-8
A-D Converters
32180 Group User's Manual (Rev.1.0)
Table 11.1.2 Registers in Which Scan Mode A-D Conversion Results Are Stored
Scan Mode Register 1 Selected channels Selected channels A-D conversion result
channel selection for single-shot scan for continuous scan storage register
B'0000:0 ADiIN0 ADiIN0 10-bit A-Di Data Register 0
(ADiIN0) Completed ADiIN0 10-bit A-Di Data Register 0
(Repeated until
forcibly terminated)
B'0001:1 ADiIN0 ADiIN0 10-bit A-Di Data Register 0
(ADiIN1) ADiIN1 ADiIN1 10-bit A-Di Data Register 1
Completed ADiIN0 10-bit A-Di Data Register 0
(Repeated until
forcibly terminated)
B'0010:2 ADiIN0 ADiIN0 10-bit A-Di Data Register 0
(ADiIN2) ADiIN1 ADiIN1 10-bit A-Di Data Register 1
ADiIN2 ADiIN2 10-bit A-Di Data Register 2
Completed ADiIN0 10-bit A-Di Data Register 0
(Repeated until
forcibly terminated)
B'0011:3 ADiIN0 ADiIN0 10-bit A-Di Data Register 0
(ADiIN3) ADiIN1 ADiIN1 10-bit A-Di Data Register 1
ADiIN2 ADiIN2 10-bit A-Di Data Register 2
ADiIN3 ADiIN3 10-bit A-Di Data Register 3
Completed ADiIN0 10-bit A-Di Data Register 0
(Repeated until
forcibly terminated)
B'XXXX:n ADiIN0 ADiIN0 10-bit A-Di Data Register 0
(ADiINn) ADiIN1 ADiIN1 10-bit A-Di Data Register 1
ADiIN2 ADiIN2 10-bit A-Di Data Register 2
n≤15
ADiINn ADiINn 10-bit A-Di Data Register n
Completed ADiIN0 10-bit A-Di Data Register 0
(Repeated until
forcibly terminated)
11.1 Outline of A-D Converters
…
…
(i=0, 1)
…
…
…
…
…
…
…
…
