13.2 CAN Module Related Registers
CAN MODULE
CAN Module Related Register Map (2/11)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1050 CAN0 Message Slot 0 Control Register CAN0 Message Slot 1 Control Register 13-53
(C0MSL0CNT) (C0MSL1CNT)
H'0080 1052 CAN0 Message Slot 2 Control Register CAN0 Message Slot 3 Control Register 13-53
(C0MSL2CNT) (C0MSL3CNT)
H'0080 1054 CAN0 Message Slot 4 Control Register CAN0 Message Slot 5 Control Register 13-53
(C0MSL4CNT) (C0MSL5CNT)
H'0080 1056 CAN0 Message Slot 6 Control Register CAN0 Message Slot 7 Control Register 13-53
(C0MSL6CNT) (C0MSL7CNT)
H'0080 1058 CAN0 Message Slot 8 Control Register CAN0 Message Slot 9 Control Register 13-53
(C0MSL8CNT) (C0MSL9CNT)
H'0080 105A CAN0 Message Slot 10 Control Register CAN0 Message Slot 11 Control Register 13-53
(C0MSL10CNT) (C0MSL11CNT)
H'0080 105C CAN0 Message Slot 12 Control Register CAN0 Message Slot 13 Control Register 13-53
(C0MSL12CNT) (C0MSL13CNT)
H'0080 105E CAN0 Message Slot 14 Control Register CAN0 Message Slot 15 Control Register 13-53
(C0MSL14CNT) (C0MSL15CNT)
(Use inhibited area)
H'0080 1100 CAN0 Message Slot 0 Standard ID0 CAN0 Message Slot 0 Standard ID1 13-57
(C0MSL0SID0) (C0MSL0SID1) 13-58
H'0080 1102 CAN0 Message Slot 0 Extended ID0 CAN0 Message Slot 0 Extended ID1 13-59
(C0MSL0EID0) (C0MSL0EID1) 13-60
H'0080 1104 CAN0 Message Slot 0 Extended ID2 CAN0 Message Slot 0 Data Length Register 13-61
(C0MSL0EID2) (C0MSL0DLC) 13-62
H'0080 1106 CAN0 Message Slot 0 Data 0 CAN0 Message Slot 0 Data 1 13-63
(C0MSL0DT0) (C0MSL0DT1) 13-64
H'0080 1108 CAN0 Message Slot 0 Data 2 CAN0 Message Slot 0 Data 3 13-65
(C0MSL0DT2) (C0MSL0DT3) 13-66
H'0080 110A CAN0 Message Slot 0 Data 4 CAN0 Message Slot 0 Data 5 13-67
(C0MSL0DT4) (C0MSL0DT5) 13-68
H'0080 110C CAN0 Message Slot 0 Data 6 CAN0 Message Slot 0 Data 7 13-69
(C0MSL0DT6) (C0MSL0DT7) 13-70
H'0080 110E CAN0 Message Slot 0 Timestamp 13-71
(C0MSL0TSP)
H'0080 1110 CAN0 Message Slot 1 Standard ID0 CAN0 Message Slot 1 Standard ID1 13-57
(C0MSL1SID0) (C0MSL1SID1) 13-58
H'0080 1112 CAN0 Message Slot 1 Extended ID0 CAN0 Message Slot 1 Extended ID1 13-59
(C0MSL1EID0) (C0MSL1EID1) 13-60
H'0080 1114 CAN0 Message Slot 1 Extended ID2 CAN0 Message Slot 1 Data Length Register 13-61
(C0MSL1EID2) (C0MSL1DLC) 13-62
H'0080 1116 CAN0 Message Slot 1 Data 0 CAN0 Message Slot 1 Data 1 13-63
(C0MSL1DT0) (C0MSL1DT1) 13-64
H'0080 1118 CAN0 Message Slot 1 Data 2 CAN0 Message Slot 1 Data 3 13-65
(C0MSL1DT2) (C0MSL1DT3) 13-66
H'0080 111A CAN0 Message Slot 1 Data 4 CAN0 Message Slot 1 Data 5 13-67
(C0MSL1DT4) (C0MSL1DT5) 13-68
H'0080 111C CAN0 Message Slot 1 Data 6 CAN0 Message Slot 1 Data 7 13-69
(C0MSL1DT6) (C0MSL1DT7) 13-70
H'0080 111E CAN0 Message Slot 1 Timestamp 13-71
(C0MSL1TSP)
H'0080 1120 CAN0 Message Slot 2 Standard ID0 CAN0 Message Slot 2 Standard ID1 13-57
(C0MSL2SID0) (C0MSL2SID1) 13-58
H'0080 1122 CAN0 Message Slot 2 Extended ID0 CAN0 Message Slot 2 Extended ID1 13-59
(C0MSL2EID0) (C0MSL2EID1) 13-60
H'0080 1124 CAN0 Message Slot 2 Extended ID2 CAN0 Message Slot 2 Data Length Register 13-61
(C0MSL2EID2) (C0MSL2DLC) 13-62
H'0080 1126 CAN0 Message Slot 2 Data 0 CAN0 Message Slot 2 Data 1 13-63
(C0MSL2DT0) (C0MSL2DT1) 13-64
H'0080 1128 CAN0 Message Slot 2 Data 2 CAN0 Message Slot 2 Data 3 13-65
(C0MSL2DT2) (C0MSL2DT3) 13-66
H'0080 112A CAN0 Message Slot 2 Data 4 CAN0 Message Slot 2 Data 5 13-67
(C0MSL2DT4) (C0MSL2DT5) 13-68
H'0080 112C CAN0 Message Slot 2 Data 6 CAN0 Message Slot 2 Data 7 13-69
(C0MSL2DT6) (C0MSL2DT7) 13-70
H'0080 112E CAN0 Message Slot 2 Timestamp 13-71
(C0MSL2TSP)
|
