Renesas M32R/ECU Series User Manual

13-7
13
32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
CAN Module Related Register Map (4/11)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1170 CAN0 Message Slot 7 Standard ID0 CAN0 Message Slot 7 Standard ID1 13-57
(C0MSL7SID0) (C0MSL7SID1) 13-58
H'0080 1172 CAN0 Message Slot 7 Extended ID0 CAN0 Message Slot 7 Extended ID1 13-59
(C0MSL7EID0) (C0MSL7EID1) 13-60
H'0080 1174 CAN0 Message Slot 7 Extended ID2 CAN0 Message Slot 6 Data Length Register 13-61
(C0MSL7EID2) (C0MSL7DLC) 13-62
H'0080 1176 CAN0 Message Slot 7 Data 0 CAN0 Message Slot 7 Data 1 13-63
(C0MSL7DT0) (C0MSL7DT1) 13-64
H'0080 1178 CAN0 Message Slot 7 Data 2 CAN0 Message Slot 7 Data 3 13-65
(C0MSL7DT2) (C0MSL7DT3) 13-66
H'0080 117A CAN0 Message Slot 7 Data 4 CAN0 Message Slot 7 Data 5 13-67
(C0MSL7DT4) (C0MSL7DT5) 13-68
H'0080 117C CAN0 Message Slot 7 Data 6 CAN0 Message Slot 7 Data 7 13-69
(C0MSL7DT6) (C0MSL7DT7) 13-70
H'0080 117E CAN0 Message Slot 7 Timestamp 13-71
(C0MSL7TSP)
H'0080 1180 CAN0 Message Slot 8 Standard ID0 CAN0 Message Slot 8 Standard ID1 13-57
(C0MSL8SID0) (C0MSL8SID1) 13-58
H'0080 1182 CAN0 Message Slot 8 Extended ID0 CAN0 Message Slot 8 Extended ID1 13-59
(C0MSL8EID0) (C0MSL8EID1) 13-60
H'0080 1184 CAN0 Message Slot 8 Extended ID2 CAN0 Message Slot 8 Data Length Register 13-61
(C0MSL8EID2) (C0MSL8DLC) 13-62
H'0080 1186 CAN0 Message Slot 8 Data 0 CAN0 Message Slot 8 Data 1 13-63
(C0MSL8DT0) (C0MSL8DT1) 13-64
H'0080 1188 CAN0 Message Slot 8 Data 2 CAN0 Message Slot 8 Data 3 13-65
(C0MSL8DT2) (C0MSL8DT3) 13-66
H'0080 118A CAN0 Message Slot 8 Data 4 CAN0 Message Slot 8 Data 5 13-67
(C0MSL8DT4) (C0MSL8DT5) 13-68
H'0080 118C CAN0 Message Slot 8 Data 6 CAN0 Message Slot 8 Data 7 13-69
(C0MSL8DT6) (C0MSL8DT7) 13-70
H'0080 118E CAN0 Message Slot 8 Timestamp 13-71
(C0MSL8TSP)
H'0080 1190 CAN0 Message Slot 9 Standard ID0 CAN0 Message Slot 9 Standard ID1 13-57
(C0MSL9SID0) (C0MSL9SID1) 13-58
H'0080 1192 CAN0 Message Slot 9 Extended ID0 CAN0 Message Slot 9 Extended ID1 13-59
(C0MSL9EID0) (C0MSL9EID1) 13-60
H'0080 1194 CAN0 Message Slot 9 Extended ID2 CAN0 Message Slot 9 Data Length Register 13-61
(C0MSL9EID2) (C0MSL9DLC) 13-62
H'0080 1196 CAN0 Message Slot 9 Data 0 CAN0 Message Slot 9 Data 1 13-63
(C0MSL9DT0) (C0MSL9DT1) 13-64
H'0080 1198 CAN0 Message Slot 9 Data 2 CAN0 Message Slot 9 Data 3 13-65
(C0MSL9DT2) (C0MSL9DT3) 13-66
H'0080 119A CAN0 Message Slot 9 Data 4 CAN0 Message Slot 9 Data 5 13-67
(C0MSL9DT4) (C0MSL9DT5) 13-68
H'0080 119C CAN0 Message Slot 9 Data 6 CAN0 Message Slot 9 Data 7 13-69
(C0MSL9DT6) (C0MSL9DT7) 13-70
H'0080 119E CAN0 Message Slot 9 Timestamp 13-71
(C0MSL9TSP)
H'0080 11A0 CAN0 Message Slot 10 Standard ID0 CAN0 Message Slot 10 Standard ID1 13-57
(C0MSL10SID0) (C0MSL10SID1) 13-58
H'0080 11A2 CAN0 Message Slot 10 Extended ID0 CAN0 Message Slot 10 Extended ID1 13-59
(C0MSL10EID0) (C0MSL10EID1) 13-60
H'0080 11A4 CAN0 Message Slot 10 Extended ID2 CAN0 Message Slot 10 Data Length Register 13-61
(C0MSL10EID2) (C0MSL10DLC) 13-62
H'0080 11A6 CAN0 Message Slot 10 Data 0 CAN0 Message Slot 10 Data 1 13-63
(C0MSL10DT0) (C0MSL10DT1) 13-64
H'0080 11A8 CAN0 Message Slot 10 Data 2 CAN0 Message Slot 10 Data 3 13-65
(C0MSL10DT2) (C0MSL10DT3) 13-66
H'0080 11AA CAN0 Message Slot 10 Data 4 CAN0 Message Slot 10 Data 5 13-67
(C0MSL10DT4) (C0MSL10DT5) 13-68
H'0080 11AC CAN0 Message Slot 10 Data 6 CAN0 Message Slot 10 Data 7 13-69
(C0MSL10DT6) (C0MSL10DT7) 13-70
H'0080 11AE CAN0 Message Slot 10 Timestamp 13-71
(C0MSL10TSP)
