Renesas M32R/ECU Series User Manual

13
13-8
32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN Module Related Register Map (5/11)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 11B0 CAN0 Message Slot 11 Standard ID0 CAN0 Message Slot 11 Standard ID1 13-57
(C0MSL11SID0) (C0MSL11SID1) 13-58
H'0080 11B2 CAN0 Message Slot 11 Extended ID0 CAN0 Message Slot 11 Extended ID1 13-59
(C0MSL11EID0) (C0MSL11EID1) 13-60
H'0080 11B4 CAN0 Message Slot 11 Extended ID2 CAN0 Message Slot 11 Data Length Register 13-61
(C0MSL11EID2) (C0MSL11DLC) 13-62
H'0080 11B6 CAN0 Message Slot 11 Data 0 CAN0 Message Slot 11 Data 1 13-63
(C0MSL11DT0) (C0MSL11DT1) 13-64
H'0080 11B8 CAN0 Message Slot 11 Data 2 CAN0 Message Slot 11 Data 3 13-65
(C0MSL11DT2) (C0MSL11DT3) 13-66
H'0080 11BA CAN0 Message Slot 11 Data 4 CAN0 Message Slot 11 Data 5 13-67
(C0MSL11DT4) (C0MSL11DT5) 13-68
H'0080 11BC CAN0 Message Slot 11 Data 6 CAN0 Message Slot 11 Data 7 13-69
(C0MSL11DT6) (C0MSL11DT7) 13-70
H'0080 11BE CAN0 Message Slot 11 Timestamp 13-71
(C0MSL11TSP)
H'0080 11C0 CAN0 Message Slot 12 Standard ID0 CAN0 Message Slot 12 Standard ID1 13-57
(C0MSL12SID0) (C0MSL12SID1) 13-58
H'0080 11C2 CAN0 Message Slot 12 Extended ID0 CAN0 Message Slot 12 Extended ID1 13-59
(C0MSL12EID0) (C0MSL12EID1) 13-60
H'0080 11C4 CAN0 Message Slot 12 Extended ID2 CAN0 Message Slot 12 Data Length Register 13-61
(C0MSL12EID2) (C0MSL12DLC) 13-62
H'0080 11C6 CAN0 Message Slot 12 Data 0 CAN0 Message Slot 12 Data 1 13-63
(C0MSL12DT0) (C0MSL12DT1) 13-64
H'0080 11C8 CAN0 Message Slot 12 Data 2 CAN0 Message Slot 12 Data 3 13-65
(C0MSL12DT2) (C0MSL12DT3) 13-66
H'0080 11CA CAN0 Message Slot 12 Data 4 CAN0 Message Slot 12 Data 5 13-67
(C0MSL12DT4) (C0MSL12DT5) 13-68
H'0080 11CC CAN0 Message Slot 12 Data 6 CAN0 Message Slot 12 Data 7 13-69
(C0MSL12DT6) (C0MSL12DT7) 13-70
H'0080 11CE CAN0 Message Slot 12 Timestamp 13-71
(C0MSL12TSP)
H'0080 11D0 CAN0 Message Slot 13 Standard ID0 CAN0 Message Slot 13 Standard ID1 13-57
(C0MSL13SID0) (C0MSL13SID1) 13-58
H'0080 11D2 CAN0 Message Slot 13 Extended ID0 CAN0 Message Slot 13 Extended ID1 13-59
(C0MSL13EID0) (C0MSL13EID1) 13-60
H'0080 11D4 CAN0 Message Slot 13 Extended ID2 CAN0 Message Slot 13 Data Length Register 13-61
(C0MSL13EID2) (C0MSL13DLC) 13-62
H'0080 11D6 CAN0 Message Slot 13 Data 0 CAN0 Message Slot 13 Data 1 13-63
(C0MSL13DT0) (C0MSL13DT1) 13-64
H'0080 11D8 CAN0 Message Slot 13 Data 2 CAN0 Message Slot 13 Data 3 13-65
(C0MSL13DT2) (C0MSL13DT3) 13-66
H'0080 11DA CAN0 Message Slot 13 Data 4 CAN0 Message Slot 13 Data 5 13-67
(C0MSL13DT4) (C0MSL13DT5) 13-68
H'0080 11DC CAN0 Message Slot 13 Data 6 CAN0 Message Slot 13 Data 7 13-69
(C0MSL13DT6) (C0MSL13DT7) 13-70
H'0080 11DE CAN0 Message Slot 13 Timestamp 13-71
(C0MSL13TSP)
H'0080 11E0 CAN0 Message Slot 14 Standard ID0 CAN0 Message Slot 14 Standard ID1 13-57
(C0MSL14SID0) (C0MSL14SID1) 13-58
H'0080 11E2 CAN0 Message Slot 14 Extended ID0 CAN0 Message Slot 14 Extended ID1 13-59
(C0MSL14EID0) (C0MSL14EID1) 13-60
H'0080 11E4 CAN0 Message Slot 14 Extended ID2 CAN0 Message Slot 14 Data Length Register 13-61
(C0MSL14EID2) (C0MSL14DLC) 13-62
H'0080 11E6 CAN0 Message Slot 14 Data 0 CAN0 Message Slot 14 Data 1 13-63
(C0MSL14DT0) (C0MSL14DT1) 13-64
H'0080 11E8 CAN0 Message Slot 14 Data 2 CAN0 Message Slot 14 Data 3 13-65
(C0MSL14DT2) (C0MSL14DT3) 13-66
H'0080 11EA CAN0 Message Slot 14 Data 4 CAN0 Message Slot 14 Data 5 13-67
(C0MSL14DT4) (C0MSL14DT5) 13-68
H'0080 11EC CAN0 Message Slot 14 Data 6 CAN0 Message Slot 14 Data 7 13-69
(C0MSL14DT6) (C0MSL14DT7) 13-70
H'0080 11EE CAN0 Message Slot 14 Timestamp 13-71
(C0MSL14TSP)
