Renesas M32R/ECU Series User Manual

13
13-10
32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN Module Related Register Map (7/11)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1440 CAN1 Single-Shot Mode Control Register 13-52
(CAN1SSMODE)
H'0080 1442 (Use inhibited area)
H'0080 1444 CAN1 Single-Shot Interrupt Request Status Register 13-33
(CAN1SSIST)
H'0080 1446 (Use inhibited area)
H'0080 1448 CAN1 Single-Shot Interrupt Request Enable Register 13-34
(CAN1SSIEN)
(Use inhibited area)
H'0080 1450 CAN1 Message Slot 0 Control Register CAN1 Message Slot 1 Control Register 13-53
(C1MSL0CNT) (C1MSL1CNT)
H'0080 1452 CAN1 Message Slot 2 Control Register CAN1 Message Slot 3 Control Register 13-53
(C1MSL2CNT) (C1MSL3CNT)
H'0080 1454 CAN1 Message Slot 4 Control Register CAN1 Message Slot 5 Control Register 13-53
(C1MSL4CNT) (C1MSL5CNT)
H'0080 1456 CAN1 Message Slot 6 Control Register CAN1 Message Slot 7 Control Register 13-53
(C1MSL6CNT) (C1MSL7CNT)
H'0080 1458 CAN1 Message Slot 8 Control Register CAN1 Message Slot 9 Control Register 13-53
(C1MSL8CNT) (C1MSL9CNT)
H'0080 145A CAN1 Message Slot 10 Control Register CAN1 Message Slot 11 Control Register 13-53
(C1MSL10CNT) (C1MSL11CNT)
H'0080 145C CAN1 Message Slot 12 Control Register CAN1 Message Slot 13 Control Register 13-53
(C1MSL12CNT) (C1MSL13CNT)
H'0080 145E CAN1 Message Slot 14 Control Register CAN1 Message Slot 15 Control Register 13-53
(C1MSL14CNT) (C1MSL15CNT)
(Use inhibited area)
H'0080 1500 CAN1 Message Slot 0 Standard ID0 CAN1 Message Slot 0 Standard ID1 13-57
(C1MSL0SID0) (C1MSL0SID1) 13-58
H'0080 1502 CAN1 Message Slot 0 Extended ID0 CAN1 Message Slot 0 Extended ID1 13-59
(C1MSL0EID0) (C1MSL0EID1) 13-60
H'0080 1504 CAN1 Message Slot 0 Extended ID2 CAN1 Message Slot 0 Data Length Register 13-61
(C1MSL0EID2) (C1MSL0DLC) 13-62
H'0080 1506 CAN1 Message Slot 0 Data 0 CAN1 Message Slot 0 Data 1 13-63
(C1MSL0DT0) (C1MSL0DT1) 13-64
H'0080 1508 CAN1 Message Slot 0 Data 2 CAN1 Message Slot 0 Data 3 13-65
(C1MSL0DT2) (C1MSL0DT3) 13-66
H'0080 150A CAN1 Message Slot 0 Data 4 CAN1 Message Slot 0 Data 5 13-67
(C1MSL0DT4) (C1MSL0DT5) 13-68
H'0080 150C CAN1 Message Slot 0 Data 6 CAN1 Message Slot 0 Data 7 13-69
(C1MSL0DT6) (C1MSL0DT7) 13-70
H'0080 150E CAN1 Message Slot 0 Timestamp 13-71
(C1MSL0TSP)
H'0080 1510 CAN1 Message Slot 1 Standard ID0 CAN1 Message Slot 1 Standard ID1 13-57
(C1MSL1SID0) (C1MSL1SID1) 13-58
H'0080 1512 CAN1 Message Slot 1 Extended ID0 CAN1 Message Slot 1 Extended ID1 13-59
(C1MSL1EID0) (C1MSL1EID1) 13-60
H'0080 1514 CAN1 Message Slot 1 Extended ID2 CAN1 Message Slot 1 Data Length Register 13-61
(C1MSL1EID2) (C1MSL1DLC) 13-62
H'0080 1516 CAN1 Message Slot 1 Data 0 CAN1 Message Slot 1 Data 1 13-63
(C1MSL1DT0) (C1MSL1DT1) 13-64
H'0080 1518 CAN1 Message Slot 1 Data 2 CAN1 Message Slot 1 Data 3 13-65
(C1MSL1DT2) (C1MSL1DT3) 13-66
H'0080 151A CAN1 Message Slot 1 Data 4 CAN1 Message Slot 1 Data 5 13-67
(C1MSL1DT4) (C1MSL1DT5) 13-68
H'0080 151C CAN1 Message Slot 1 Data 6 CAN1 Message Slot 1 Data 7 13-69
(C1MSL1DT6) (C1MSL1DT7) 13-70
H'0080 151E CAN1 Message Slot 1 Timestamp 13-71
(C1MSL1TSP)
|
|
