Renesas M32R/ECU Series User Manual

13
13-12
32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN Module Related Register Map (9/11)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1560 CAN1 Message Slot 6 Standard ID0 CAN1 Message Slot 6 Standard ID1 13-57
(C1MSL6SID0) (C1MSL6SID1) 13-58
H'0080 1562 CAN1 Message Slot 6 Extended ID0 CAN1 Message Slot 6 Extended ID1 13-59
(C1MSL6EID0) (C1MSL6EID1) 13-60
H'0080 1564 CAN1 Message Slot 6 Extended ID2 CAN1 Message Slot 6 Data Length Register 13-61
(C1MSL6EID2) (C1MSL6DLC) 13-62
H'0080 1566 CAN1 Message Slot 6 Data 0 CAN1 Message Slot 6 Data 1 13-63
(C1MSL6DT0) (C1MSL6DT1) 13-64
H'0080 1568 CAN1 Message Slot 6 Data 2 CAN1 Message Slot 6 Data 3 13-65
(C1MSL6DT2) (C1MSL6DT3) 13-66
H'0080 156A CAN1 Message Slot 6 Data 4 CAN1 Message Slot 6 Data 5 13-67
(C1MSL6DT4) (C1MSL6DT5) 13-68
H'0080 156C CAN1 Message Slot 6 Data 6 CAN1 Message Slot 6 Data 7 13-69
(C1MSL6DT6) (C1MSL6DT7) 13-70
H'0080 156E CAN1 Message Slot 6 Timestamp 13-71
(C1MSL6TSP)
H'0080 1570 CAN1 Message Slot 7 Standard ID0 CAN1 Message Slot 7 Standard ID1 13-57
(C1MSL7SID0) (C1MSL7SID1) 13-58
H'0080 1572 CAN1 Message Slot 7 Extended ID0 CAN1 Message Slot 7 Extended ID1 13-59
(C1MSL7EID0) (C1MSL7EID1) 13-60
H'0080 1574 CAN1 Message Slot 7 Extended ID2 CAN1 Message Slot 7 Data Length Register 13-61
(C1MSL7EID2) (C1MSL7DLC) 13-62
H'0080 1576 CAN1 Message Slot 7 Data 0 CAN1 Message Slot 7 Data 1 13-63
(C1MSL7DT0) (C1MSL7DT1) 13-64
H'0080 1578 CAN1 Message Slot 7 Data 2 CAN1 Message Slot 7 Data 3 13-65
(C1MSL7DT2) (C1MSL7DT3) 13-66
H'0080 157A CAN1 Message Slot 7 Data 4 CAN1 Message Slot 7 Data 5 13-67
(C1MSL7DT4) (C1MSL7DT5) 13-68
H'0080 157C CAN1 Message Slot 7 Data 6 CAN1 Message Slot 7 Data 7 13-69
(C1MSL7DT6) (C1MSL7DT7) 13-70
H'0080 157E CAN1 Message Slot 7 Timestamp 13-71
(C1MSL7TSP)
H'0080 1580 CAN1 Message Slot 8 Standard ID0 CAN1 Message Slot 8 Standard ID1 13-57
(C1MSL8SID0) (C1MSL8SID1) 13-58
H'0080 1582 CAN1 Message Slot 8 Extended ID0 CAN1 Message Slot 8 Extended ID1 13-59
(C1MSL8EID0) (C1MSL8EID1) 13-60
H'0080 1584 CAN1 Message Slot 8 Extended ID2 CAN1 Message Slot 8 Data Length Register 13-61
(C1MSL8EID2) (C1MSL8DLC) 13-62
H'0080 1586 CAN1 Message Slot 8 Data 0 CAN1 Message Slot 8 Data 1 13-63
(C1MSL8DT0) (C1MSL8DT1) 13-64
H'0080 1588 CAN1 Message Slot 8 Data 2 CAN1 Message Slot 8 Data 3 13-65
(C1MSL8DT2) (C1MSL8DT3) 13-66
H'0080 158A CAN1 Message Slot 8 Data 4 CAN1 Message Slot 8 Data 5 13-67
(C1MSL8DT4) (C1MSL8DT5) 13-68
H'0080 158C CAN1 Message Slot 8 Data 6 CAN1 Message Slot 8 Data 7 13-69
(C1MSL8DT6) (C1MSL8DT7) 13-70
H'0080 158E CAN1 Message Slot 8 Timestamp 13-71
(C1MSL8TSP)
H'0080 1590 CAN1 Message Slot 9 Standard ID0 CAN1 Message Slot 9 Standard ID1 13-57
(C1MSL9SID0) (C1MSL9SID1) 13-58
H'0080 1592 CAN1 Message Slot 9 Extended ID0 CAN1 Message Slot 9 Extended ID1 13-59
(C1MSL9EID0) (C1MSL9EID1) 13-60
H'0080 1594 CAN1 Message Slot 9 Extended ID2 CAN1 Message Slot 9 Data Length Register 13-61
(C1MSL9EID2) (C1MSL9DLC) 13-62
H'0080 1596 CAN1 Message Slot 9 Data 0 CAN1 Message Slot 9 Data 1 13-63
(C1MSL9DT0) (C1MSL9DT1) 13-64
H'0080 1598 CAN1 Message Slot 9 Data 2 CAN1 Message Slot 9 Data 3 13-65
(C1MSL9DT2) (C1MSL9DT3) 13-66
H'0080 159A CAN1 Message Slot 9 Data 4 CAN1 Message Slot 9 Data 5 13-67
(C1MSL9DT4) (C1MSL9DT5) 13-68
H'0080 159C CAN1 Message Slot 9 Data 6 CAN1 Message Slot 9 Data 7 13-69
(C1MSL9DT6) (C1MSL9DT7) 13-70
H'0080 159E CAN1 Message Slot 9 Timestamp 13-71
(C1MSL9TSP)
