32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN Module Related Register Map (11/11)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 15E0 CAN1 Message Slot 14 Standard ID0 CAN1 Message Slot 14 Standard ID1 13-57
(C1MSL14SID0) (C1MSL14SID1) 13-58
H'0080 15E2 CAN1 Message Slot 14 Extended ID0 CAN1 Message Slot 14 Extended ID1 13-59
(C1MSL14EID0) (C1MSL14EID1) 13-60
H'0080 15E4 CAN1 Message Slot 14 Extended ID2 CAN1 Message Slot 14 Data Length Register 13-61
(C1MSL14EID2) (C1MSL14DLC) 13-62
H'0080 15E6 CAN1 Message Slot 14 Data 0 CAN1 Message Slot 14 Data 1 13-63
(C1MSL14DT0) (C1MSL14DT1) 13-64
H'0080 15E8 CAN1 Message Slot 14 Data 2 CAN1 Message Slot 14 Data 3 13-65
(C1MSL14DT2) (C1MSL14DT3) 13-66
H'0080 15EA CAN1 Message Slot 14 Data 4 CAN1 Message Slot 14 Data 5 13-67
(C1MSL14DT4) (C1MSL14DT5) 13-68
H'0080 15EC CAN1 Message Slot 14 Data 6 CAN1 Message Slot 14 Data 7 13-69
(C1MSL14DT6) (C1MSL14DT7) 13-70
H'0080 15EE CAN1 Message Slot 14 Timestamp 13-71
(C1MSL14TSP)
H'0080 15F0 CAN1 Message Slot 15 Standard ID0 CAN1 Message Slot 15 Standard ID1 13-57
(C1MSL15SID0) (C1MSL15SID1) 13-58
H'0080 15F2 CAN1 Message Slot 15 Extended ID0 CAN1 Message Slot 15 Extended ID1 13-59
(C1MSL15EID0) (C1MSL15EID1) 13-60
H'0080 15F4 CAN1 Message Slot 15 Extended ID2 CAN1 Message Slot 15 Data Length Register 13-61
(C1MSL15EID2) (C1MSL15DLC) 13-62
H'0080 15F6 CAN1 Message Slot 15 Data 0 CAN1 Message Slot 15 Data 1 13-63
(C1MSL15DT0) (C1MSL15DT1) 13-64
H'0080 15F8 CAN1 Message Slot 15 Data 2 CAN1 Message Slot 15 Data 3 13-65
(C1MSL15DT2) (C1MSL15DT3) 13-66
H'0080 15FA CAN1 Message Slot 15 Data 4 CAN1 Message Slot 15 Data 5 13-67
(C1MSL15DT4) (C1MSL15DT5) 13-68
H'0080 15FC CAN1 Message Slot 15 Data 6 CAN1 Message Slot 15 Data 7 13-69
(C1MSL15DT6) (C1MSL15DT7) 13-70
H'0080 15FE CAN1 Message Slot 15 Timestamp 13-71
(C1MSL15TSP)
